Section
IMPORTANT!
• The repeater list, described in this manual, may differ from your transceiver's preloaded contents
• Although Japanese repeaters are used in the setting examples, the Japanese repeater node (port) letters are
different from other country's
BE SURE to add the repeater node letter in the 8th digit of the call sign, according to the frequency band
shown below
1200 MHz : A (B in Japan)
430 MHz : B (A in Japan)
144 MHz : C (no D-STAR repeaters in Japan)
To begin the Digital mode communication using other than the D-STAR Repeater (DR) function
To begin Digital mode communication using other
than the DR function, you can use the VFO mode,
Memory mode, or Call channel mode
This manual description focuses on the DR function
operation which can be easily set up If you want to
use other than the DR function, see the procedures
as described to the right, or select the repeater in a
Memory channel
D-STAR OPERATION
Data communication 4-27
D Connection 4-27
D Data communication application setting 4-27
D Sending data 4-27
D DV Fast Data function 4-28
Digital squelch functions 4-29
D The Digital Call Sign squelch setting 4-29
D Digital call sign squelch function with the Pocket beep 4-29
D The Digital Code Squelch setting 4-30
D Digital code squelch function with a Pocket beep 4-30
Repeater list 4-31
D Repeater list contents 4-31
Entering new information into the repeater list 4-32
D Required items for the communication cases 4-32
D Entering new information into the repeater list 4-33
Repeater list operation 4-37
D Editing repeater data 4-37
D Deleting repeater data 4-37
D Rearranging the display order of the repeaters 4-38
D Adding a new repeater information from RX History 4-38
D Skip setting for the DR scan 4-39
D Entering or editing a repeater group name 4-40
Your Call Sign 4-41
D Entering Your Call Sign 4-41
D Deleting Your Call Sign 4-42
D Rearranging the display order of Your Call Signs 4-42
Are your settings correct?4-43
For a Local area call or Gateway call:
1 Set the access repeater's frequency (p 10-2)
2 Set the frequency offset for the Duplex operation.
(p 10-4)
3 Set the Duplex direction. (p. 10-4)
4 Set the call signs (UR/R1/R2) (p 11-19)
For a Simplex call:
1 Set the operating mode to the DV mode
2 Set the operating frequency
(BASIC MANUAL p 51)
