Complete the Two-Monitor Setup (HDMI Splitter or HDMI USB
Adapter)
Once you have connected your Pano system, Polycom video system, and two monitors (using an HDMI
splitter or HDMI USB adapter), you can finish the setup.
You must connect the splitter or adapter (depending on your setup method) before you can complete the
following steps.
Procedure
1. Configure your Pano system monitor settings:
a. Open a browser and enter the IP address of the Pano system.
b. Go to General Settings > Monitor.
c. Select Automatic for the Configure Monitor option.
Note: If you instead choose to manually configure your monitor, make sure it supports
your selected resolution. An unsupported resolution can cause display issues.
Your changes automatically save, and the monitor adjusts to the configured resolution.
2. Configure the monitor profile for your Polycom video system monitor:
a. Open a browser and enter the IP address of the Polycom video system.
b. Go to Admin Settings > Audio/Video > Monitors.
c. For Monitor 1 at Monitor Profile, select Content, then Far, then Near.
3. Restart the Polycom video system.
4. Connect one end of an HDMI cable to the Polycom video system HDMI Input port (see images
below for port location). (For RealPresence Group 700 systems, you must connect the HDMI cable
to Input port 3.)
