Input 1; Table 10-21 Set-Up Group - Input 1 - Honeywell UDC3500 Product Manual

10.7.12

Input 1

Table 10-21 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Input 1.
Parameter
Description
Input 1 Type 168
ATTENTION
3/07
Modbus Read, Write and Override Parameters plus Exception Codes
Table 10-21 Set-up Group – Input 1
Register
Address
ID Hex Decimal
00A8 168
UDC3500 Universal Digital Controller Product Manual
Data Access
Type
INT R/W
Data Range or
Enumerated Selection
1 = B TC
2 = E TC H
3 = E TC L
4 = J TC H
5 = J TC M
6 = J TC L
7 = K TC H
8 = K TC M
9 = K TC L
10 = NNM H
11 = NNM L
12 = Nicrosil H TC
13 = Nicrosil L TC
14 = Plat H
15 = Plat L
16 = R TC
17 = S TC
18 = T TC H
19= T TC L
20 = W TC H
21 = W TC L
22 = 100 PT RTD
23 = 100 PT LO RTD
24 = 200 PT RTD
25 = 500 PT RTD
26 = 1000PT
27 = Radiamatic RH
28 = Radiamatic RI
29 = 0-20 mA
30 = 4-20 mA
31 = 0-10 mV
32 = 0-50 mV
33 = 100 mV
34 = 0-500mV
35 = -10-10mV
36 = 0-1V
37 = 0-5 Vdc
38 = 1-5 Vdc
39 = 0-10 Vdc
40 = -1-1V
41 = Unused
42 = Carbon
43 = Oxygen
44 = Thermocouple
Differential
45 = Unused
46 = PR
401
