Troubleshooting/Service
• Ethernet Communications Failure
• Email Failure
7.8 Restore Factory Configuration
7.9 Software Upgrades
Installation related problems
Read the Installation section in this manual to make sure the instrument has been
properly installed. The installation section provides information on protection against
electrical noise, connecting external equipment to the controller, and shielding and
routing external wiring.
ATTENTION
messages recurring. If the diagnostic error messages can be cleared, it indicates a "soft"
failure and is probably noise related.
If system noise is suspected, completely isolate the controller from all field wiring.
Use calibration sources to simulate PV and check all controller functions; i.e. Gain, Rate,
Reset, Output, Alarms, etc.
See Section 11.3 for further information.
Application related problems
Review the application of the controller; then, if necessary, direct your questions to the
local sales office.
Hardware and software related problems
Use the troubleshooting error message prompts and controller failure symptoms to
identify typical failures that may occur in the controller. Follow the troubleshooting
procedures to correct them.

7.2 Troubleshooting Aids

Overall error messages
An error message can occur:
• At power-up. See Subsection 7.3.
• When the Status Tests are requested. See Subsection 7.4.
• During continuous background tests while in normal operation. See Subsection 7.5.
308
TOPIC
System noise induced into the controller will result in diagnostic error
UDC3500 Universal Digital Controller Product Manual
See Page
331
332
333
3/07
