Deutz Td 2.9 L4 Engine Fault Codes - Genie S-100 Service And Repair Manual

March 2017
SPN = Suspect Parameter Number
FMI = Failure Mode Identifier
KWP = Keyword Protocol
SPN FMI KWP Description
51 3 1019 EGR-Valve, short circuit to
battery
51 3 1024 Position sensor error of actuator
EGR-Valve; signal range check
high
51 3 1226 EGR-Valve; short circuit to
battery (A02)
51 3 1227 EGR-Valve; short circuit to
battery (A67)
51 4 1020 EGR-Valve; short circuit to
ground
51 4 1025 Position sensor error of actuator
EGR-Valve; signal range check
low
51 4 1228 EGR-Valve; short circuit to
ground (A02)
51 4 1229 EGR-Valve; short circuit to
ground (A67)
51 4 1232 Actuator error EGR-Valve;
Voltage below threshold
51 5 1015 Actuator error EGR-Valve; signal
range check low
51 5 1017 Actuator EGR-Valve; open load
51 5 1023 Actuator error EGR-Valve; signal
range check low
51 5 1223 Actuator EGR-Valve; open load
51 6 1014 Actuator error EGR-Valve; signal
range check high
Part No. 1268494
SPN FMI KWP
51
51
51
51
51
51
51
51
94
94
94
94
97
97
97
S-100 • S-105 • S-120 • S-125
Section 4 • Diagnostic Codes

DEUTZ TD 2.9 L4 ENGINE FAULT CODES

Description
6 1022 Actuator error EGR-Valve; signal
range check high
6 1224 Actuator EGR-Valve; over
current
6 1230 Actuator error EGR-Valve;
Overload by short-circuit
7 1016 Actuator position for EGR-Valve
not plausible
11 1231 Actuator error EGR-Valve; Power
stage over temp due to high
current
12 1018 Actuator EGR-Valve; powerstage
over temperature
12 1021 Mechanical actuator defect
EGR-Valve
12 1225 Actuator EGR-Valve;
over temperature
1 474 Low fuel pressure; warning
threshold exceeded
1 475 Low fuel pressure; shut off
threshold exceeded
3 472 Sensor error low fuel pressure;
signal range check high
4 473 Sensor error low fuel pressure;
signal range check low
3 464 Sensor error water fuel; signal
range check high
4 465 Sensor error water fuel; signal
range check low
12 1157 Water in fuel level prefilter;
maximum value exceeded
4 - 13
