Daikin RZQ100B8V3B Service Manual page 40

Specifications
1 1
Electrical
specifications
Specification
Power supply
Current
Voltage range
Wire connections
3
Power supply intake
Notes
4
Electrical data
Unit combination
Indoor unit Outdoor unit
FCQ100DV3B RZQ100B7W1B
FCQ100B7V3B RZQ100B7W1B
FCQ50B7V1x2 RZQ100B7W1B
5
FCQ35B7V1x3 RZQ100B7W1B
FFQ50B7V1Bx2 RZQ100B7W1B
FFQ35B7V1Bx3 RZQ100B7W1B
FBQ100B7V3B RZQ100B7W1B
FBQ50B7V1x2 RZQ100B7W1B
FBQ35B7V1x3 RZQ100B7W1B
FHQ100BUV1B RZQ100B7W1B
FHQ50BUV1Bx2 RZQ100B7W1B
FHQ35BUV1Bx3 RZQ100B7W1B
FAQ100BUV1B RZQ100B7W1B
FUQ100BUV1B RZQ100B7W1B
FCQ125DV3B RZQ125B7W1B
FCQ125B7V3B RZQ125B7W1B
FCQ60B7V1x2 RZQ125B7W1B
FCQ50B7V1x3 RZQ125B7W1B
FCQ35B7V1x4 RZQ125B7W1B
FFQ60B7V1Bx2 RZQ125B7W1B
FFQ50B7V1Bx3 RZQ125B7W1B
FFQ35B7V1Bx4 RZQ125B7W1B
FBQ125B7V3B RZQ125B7W1B
FBQ60B7V1x2 RZQ125B7W1B
FBQ50B7V1x3 RZQ125B7W1B
FBQ35B7V1x4 RZQ125B7W1B
FHQ125BUV1B RZQ125B7W1B
FHQ60BUV1Bx2 RZQ125B7W1B
FHQ50BUV1Bx3 RZQ125B7W1B
FHQ35BUV1Bx4 RZQ125B7W1B
FUQ125BUV1B RZQ125B7W1B
FDQ125B7V3B RZQ125B7W1B
1–18
The table below contains the electrical specifications.
Name
Phase
Frequency
Voltage
Zmax. List
Recommended fuses
Mininum
Maximum
For power supply - remark
For connection with indoor - remark
Power supply
Hz-Volts Voltage range MCA
50-400 14.2
50-400 14.5
50-400 14.7
50-400 15.3
50-400 14.9
50-400 15.3
50-400 14.5
Max.50Hz-440V
Min.50Hz-360V
50-400 14.9
50-400 15.0
50-400 14.2
50-400 14.7
50-400 15.3
50-400 13.9
50-400 14.6
50-400 14.2
50-400 14.5
50-400 14.7
50-400 15.3
50-400 15.9
50-400 14.9
50-400 15.6
50-400 15.9
50-400 14.9
Max.50Hz-440V
Min.50Hz-360V
50-400 15.3
50-400 15.6
50-400 15.5
50-400 14.2
50-400 14.7
50-400 15.3
50-400 15.9
50-400 14.6
50-400 17.7
RZQ100B7W1B RZQ125B7W1B
Complies to EN61000-3-11
See installation manual 4PW21412-1
See installation manual 4PW21412-1
Outdoor unit only
See separate drawing for See separate drawing for
electrical data. electrical data.
Power supply intake for FDQ is
outdoor and indoor unit.
Compressor
TOCA MFA MSC RLA
14.2 20 12.9 12.9
14.5 20 12.9 12.9
14.7 20 12.9 12.9
15.3 20 12.9 12.9
14.9 20 12.9 12.9
15.3 20 12.9 12.9
14.5 20 12.9 12.9
14.9 20 12.9 12.9
15.0 20 12.9 12.9
14.2 20 12.9 12.9
14.7 20 12.9 12.9
15.3 20 12.9 12.9
13.9 20 12.9 12.9
14.6 20 12.9 12.9
14.2 20 12.9 12.9
14.5 20 12.9 12.9
14.7 20 12.9 12.9
15.3 20 12.9 12.9
15.9 20 12.9 12.9
14.9 20 12.9 12.9
15.6 20 12.9 12.9
15.9 20 12.9 12.9
14.9 20 12.9 12.9
15.3 20 12.9 12.9
15.6 20 12.9 12.9
15.5 20 12.9 12.9
14.2 20 12.9 12.9
14.7 20 12.9 12.9
15.3 20 12.9 12.9
15.9 20 12.9 12.9
14.6 20 12.9 12.9
17.7 20 12.9 12.9
ESIE05-03
RZQ140B7W1B
W1B
3N~
50 Hz
400 V
20 A
360 V
440 V
See separate drawing for
electrical data.
OFM IFM
kW FLA kW
0.07+0.07 0.3+0.3 0.120
0.07+0.07 0.3+0.3 0.090
0.07+0.07 0.3+0.3 0.045x2
0.07+0.07 0.3+0.3 0.045x3
0.07+0.07 0.3+0.3 0.055x2
0.07+0.07 0.3+0.3 0.055x3
0.07+0.07 0.3+0.3 0.135
0.07+0.07 0.3+0.3 0.085x2
0.07+0.07 0.3+0.3 0.065x3
0.07+0.07 0.3+0.3 0.130
0.07+0.07 0.3+0.3 0.062x2
0.07+0.07 0.3+0.3 0.062x3
0.07+0.07 0.3+0.3 0.049
0.07+0.07 0.3+0.3 0.090
0.07+0.07 0.3+0.3 0.120
0.07+0.07 0.3+0.3 0.090
0.07+0.07 0.3+0.3 0.045x2
0.07+0.07 0.3+0.3 0.045x3
0.07+0.07 0.3+0.3 0.045x4
0.07+0.07 0.3+0.3 0.055x2
0.07+0.07 0.3+0.3 0.055x3
0.07+0.07 0.3+0.3 0.055x4
0.07+0.07 0.3+0.3 0.225
0.07+0.07 0.3+0.3 0.125x2
0.07+0.07 0.3+0.3 0.085x3
0.07+0.07 0.3+0.3 0.065x4
0.07+0.07 0.3+0.3 0.130
0.07+0.07 0.3+0.3 0.062x2
0.07+0.07 0.3+0.3 0.062x3
0.07+0.07 0.3+0.3 0.062x4
0.07+0.07 0.3+0.3 0.090
0.07+0.07 0.3+0.3 0.500
Part 1 – System Outline
FLA
0.7
1.0
0.6x2
0.6x3
0.7x2
0.6x3
1.0
0.7x2
0.5x3
0.7
0.6x2
0.6x3
0.4
1.1
0.7
1.0
0.6x2
0.6x3
0.6x4
0.7x2
0.7x3
0.6x4
1.4
0.9x2
0.7x3
0.5x4
0.7
0.6x2
0.6x3
0.6x4
1.1
4.2
