Field settings
1
3
4
5
DIP switches
DIP
Label on PCB
switch
DS1-1 ON/OFF
DS1-2 Cool / Heat
DS1-3 ON/OFF
DS1-4 ON/OFF
BS
BS Label on PCB
BS BS1
4–22
This drawing shows the position of jumper JX5 on PCB A1P.
The table below contains the DIP switch field settings.
Function
Switch emergency operation outdoor unit ON/OFF.
Select cooling / heating emergency operation.
Test purposes only. Keep factory setting "OFF".
Test purposes only. Keep factory setting "OFF".
The table below contains the BS field setting.
Function
Cooling / fan only: Pump down
Heating: Forced defrosting function
ESIE05-03
Details
See page 2-6.
See page 2-6.
—
—
Details
See page 2-18.
See page 2-6.
Part 4 – Commissioning and Test Run
