SPLIT SYSTEM
MODEL
RZQ18TBVJUA
RZR18TBVJUA
RZQ24TBVJUA
RZR24TBVJUA
RZQ30TBVJUA
RZR30TBVJUA
RZQ36TBVJUA
RZR36TBVJUA
RZQ42TBVJUA
RZR42TBVJUA
RZQ48TBVJUA
RZR48TBVJUA
INSTALLATION MANUAL
Read these instructions carefully before installation.
Keep this manual in a handy place for future reference.
This manual should be left with the equipment owner.
Lire soigneusement ces instructions avant l'installation.
Conserver ce manuel à portée de main pour référence ultérieure.
