FP optimail 30 Operator's Manual page 99

Hold leg spring
in place!
Moistening felt correctly
positioned:
Projection
1-2 mm
Correcting the moistening felt position
on the rocker
• Slightly tilt the rocker and pull it off in an
Caution! Make sure to always hold the leg
spring on the pin with one hand while posi-
tioning the moistening felt. This will prevent
the leg spring from jamming or jumping out.
• Push the long moistening felt side fully
Moistening felt
• Carefully displace the moistening felt in the
Aligned with
stop edge
• Reattach the rocker on the sealer
obliquely upward direction.
underneath the clamping strip such that
– the felt's recesses are perfectly aligned
with the rocker stop edge and
– both moistening felt outer edges uni-
formly project over the rocker edge by
approximately 1 - 2 mm (0,04" - 0,08").
See illustration.
clamping strip if necessary.
(see page 90).
Tips for troubleshooting
