3.4 Cabling to the CIO-DAC##-I

The CIO-DAC##-I connector is accessible through the PC/AT expansion bracket.
The connector is a standard 37-pin D-type male connector.
connector, such as the C37FF-2, is available from Measurement Computing.
Several cabling and screw termination options are available from Measurement
Computing.
DFCON-37
C37FF-2
C37FFS-5
CIO-MINI37
CIO-TERMINAL
CIO-SPADE 50

3.5 Testing the Installation

You can test the installation of the CIO-DAC##-I using InstaCal. Select the Test
option to vary the output voltages and monitor them with a Volt Meter.
D connector, D shell and termination pins to
construct your own cable
2 foot (and longer) ribbon cable with 37 pin D
female connectors
5 foot shielded round cable with molded ends
housing 37-pin female connectors. Also in 10 ft.
37-position, 4 X 4-in. screw terminal board
4 X 16-in. screw terminal board with on-board
prototyping area.
A screw terminal board that accepts spade lugs with
on-board area for prototyping circuitry.
