Chapter 3 — Replacing Parts

Replacing the Main Board

70
The electronic compartment contains wires and components with
dangerous voltage. Always switch off the power and unplug the power
cord before you remove the cover over the electronics compartment!
Im Elektronikfach gibt es Kabel und Komponenten, die hohe
Spannungen führen. Immer die Stromversorgung abschalten und das
Netzkabel abziehen, bevor die Abdeckung des Elektronikfachs
abgenommen wird!
Do not attempt to replace individual components on the main board.
Replace the entire board instead.
Nicht versuchen, einzelne Komponenten auf der Hauptplatine
auszutauschen. Es muss die gesamte Platine ausgetauscht werden.
Take standard precautions against ESD (Electrostatic Discharges)
before touching any electronics components.
To replace the main board
1 Disconnect the power cord and remove the left-hand panel (For help,
see "To remove the left-hand panel" on page
2 Disconnect all cables from the main board (it may be a good idea to
label them first).
3 Remove any CompactFlash memory card.
4 Remove any Ethernet and parallel interface option boards.
5 Remove the five screws and washers that hold the main board.
6 Lift out the main board and install in reverse order.
27).
