Chapter 2 — Models and Options

Technical Specifications

EasyCoder PD41 Printer
14
Physical Dimensions
Dimensions (WxLxH)
Weight (excl. media)
Power Supply
Input rating
Power consumption
Printing
Print technique
Printhead resolutions
Print speed
8 dots/mm (203 dpi)
11.8 dots/mm (300dpi)
Print Width Max.
8 dots/mm (203 dpi)
11.8 dots/mm (300dpi)
Print Length Max.
8 dots/mm (203 dpi)
11.8 dots/mm (300dpi)
Modes of Operation
Tear-off (straight-through)
Cut-off
Peel-off (self-strip)
Firmware (Fingerprint)
Operating system
Smooth fonts
Resident scalable fonts
Character sets
Resident bar codes
276 x 454.4 x 283.0 mm
(10.9 x 17.9 x 11.2 in)
13 kg (28.7 pounds)
~
100-240V 2-1A 50/60 Hz
• Stand-by: 12 W
• Normal operation/printing: 80 W
• Peak: 250 in
Direct Thermal/Thermal Transfer
8 dots/mm (203.2 dpi) or
11.8 dots/mm (300 dpi)
50.8 to 152.4 mm/sec (2 to 6 in/sec)
50.8 to 101.6 mm/sec (2 to 4 in/sec)
104 mm (4.1 in)
105.7 mm (4.2 in)
Fingerprint
1270 mm (50 in)
558.2 mm (22 in)
Yes
Option with cutter
Option with internal
rewinder
Fingerprint v10.x.x
TrueType and TrueDoc fonts
15
• 23 single-byte character sets standard.
• UTF-8 support as standard.
61
EasyCoder PD41/PD42 Printer Service Manual
IPL
600 mm (23 in)
406.4 mm (16 in)
Includes Direct Protocol
