Chapter 1 — Troubleshooting the PD41/PD42

Error Handling

Display Error Messages (Blue Ready-to-Work LED Blinks)
Error Symbol Error Message
Printhead lifted
Maintenance
IP link error
Press feed not done Press Feed( ) or Testfeed(
2
The EasyCoder PD41/PD42 printer communicates errors to the user via
the red Error LED and the blue Ready-to-Work LED on the front panel.
When an error condition occurs, these two will be turned on or flash
depending on the cause of the error. On the PD42, additional error
information is communicated through the display.
LEDs and the Print button
When all errors have been cleared, the Error LED is turned off, the error
message disappears from the display and the Ready-to-Work indicator is
turned back on.
Solution
Lower printhead.
The printer is upgrading its firmware. Wait for it to complete the task.
Check if the network cable has been unplugged
)
EasyCoder PD41/PD42 Printer Service Manual
