Page 2: Safety Rules
1. SAFETY RULES 1. To reduce the risk of electric shock, insure 8. WARNING: Use only with light kit marked electricity has been turned off at the circuit "Suitable for Use in Damp Locations". breaker or fuse box before beginning. 9. -
Page 3: Tools And Materials Required
Canfield 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Fan blades (5) Hanger bracket and canopy... -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing UL (CUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers Secure the outlet box directly to the building Outlet box structure. -
Page 5: Hanging The Fan
Canfield 5. HANGING THE FAN Hanger bracket REMEMBER to turn off the power. Follow the steps below to hang your fan properly. NOTE: This ceiling fan is supplied with two types of Ceiling hanging assemblies; the standard ceiling canopy installation using the downrod with ball and socket mounting and the "close-to-ceiling"... - Page 6 Step 7. Slip coupling cover, canopy ring and canopy onto downrod. Carefully reinstall hanger ball onto rod being sure that cross pin Downrod is in correct position, the set screw on hanger Canopy ball is tight and wires are not twisted. (Fig. 9) Step 8.
- Page 7 Canfield CLOSE-TO-CEILING INSTALLATION Canopy 1. Remove the decorative canopy cover from the canopy. (Fig. 11) 2. Pass the 120-volt supply wires through the center hole in the ceiling hanger bracket as Canopy cover shown in Fig. 6. Fig. 11 3. Secure the hanger bracket to the ceiling...
-
Page 8: Installation Of Safety Support
6. INSTALLATION OF SAFETY SUPPORT (for Canadian Installation ONLY) An additional safety support is provided to prevent the fan from falling fan). Place the end Hanger bracket Attach safety cable of cable through the loop of ceiling support to ceiling joist with cable. -
Page 9: Finishing The Installation
Canfield Figures 16 and 17 illustrate the wiring POWER LINES 120V connections for optional wall control (The wire GREEN color out of wall control may vary, see wall GROUND control's installation manual for correct wire WIRING LIGHT connections.) GROUND TO... -
Page 10: Attaching The Fan Blades
9. ATTACHING THE FAN BLADES Caution: Remove 5 rubber packing mounts and discard before installation. Step 1 Attach the blade to the blade bracket using the screws, washers and rubber washers as shown in Fig. 20. Start screw into bracket. Repeat for the two remaining screws. Step 2 Make sure the blade is straight and Screws tighten each screw. -
Page 11: Installing The Switch Housing
Canfield 11. INSTALLING THE SWITCH HOUSING NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. - Page 12 12. OPERATING INSTRUCTIONS Turn on the power and check the operation of your fan. The pull chain controls the fan speed as follows: 1. 3-speed pull chain- it controls the fan speed as follows: 1 pull- High, 2 pulls- Medium, 3 pulls- Low, and 4 pulls- Off.
-
Page 13: Troubleshooting
Canfield 13. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds noisy.
