- Page 1 Cortez A Kichler ® Décor ™ Ceiling Fan Kichler Lighting ® 7711 East Pleasant Valley Road P.O. Box 318010 Instruction Manual Cleveland, Ohio 44131-8010 Customer Service 866.558.5706 8:30 AM to 5:00 PM EST, Monday - Friday...
- Page 2 1. SAFETY RULES 1. To reduce the risk of electric shock, insure 8. Avoid placing objects in the path of the electricity has been turned off at the circuit blades. breaker or fuse box before beginning. 9. To avoid personal injury or damage to the fan and other items, be cautious when 2.
-
Page 3: Table Of Contents
Cortez 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Slot screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Fan Blade (5) Mounting Bracket (1) Canopy (1) Canopy Décor (1) - Page 4 4. MOUNTING OPTIONS If there isn't an existing UL ( CUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure.
-
Page 5: Mounting Bracket
Corez 5. HANGING THE FAN Motor REMEMBER to turn off the power. Follow the Screw steps below to hang your fan properly: Down Housing Step 1. Remove the down housing, upper glass bowl and motor from the protective plastic bag and take the lower Styrofoam packing pad out of the carton. -
Page 6: Canopy
Step 6. Carefully pass the upper glass bowl Mounting Plate over the downrod and let it rest on top of the motor housing. Remove the acorn nut from the screw stem (Fig. 9). Align the slot on the mounting plate with the screw stem on the motor housing. - Page 7 Cortez 6. INSTALLATION OF SAFETY SUPPORT 3 mm( 1 / 8 ") Wood Screw Ceiling Joist ( For Canadian Installation ONLY ) Outlet Box A safety support cable is provided to help Ceiling prevent the ceiling fan from falling, please install it as follows.
- Page 8 8. INSTALLING THE CEILING CANOPY Outlet box WARNING: One last time, make sure the “Check Tab” at the bottom of the hanger bracket is properly seated in the “Registration Slot” on the side of the hanger ball before attaching the canopy to the bracket.
-
Page 9: Mounting Plate
Cortez 10. INSTALLING THE MOUNTING PLATE Step 1. Remove 1 of the 3 screws in the mounting ring and loosen the other 2 screws, do not remove (The mounting ring located on the motor shaft). Step 2. Place the key holes on the mounting... -
Page 10: Fob
12. INSTALLING THE FOB Step 1. Attach the decorative pull chain Fob to the pull chain coming out of the Switch Housing. Refer to Fig. 20 Step 2. The longer pull chain is for motor speed control and it has four positions. High, Medium, Low and Off. - Page 11 Cortez Step 6. Tuck the connections neatly into the switch housing. Align the key hole on the switch housing with the 2 screws on the side of the mounting plate. Turn the light fixture until it locks in place at the narrow end of the key holes.
- Page 12 14. TROUBLESHOOTING Problem & Solution Fan will not operate: 1. Check main circuit breakers or fuses. 2. Check all main wiring connections to the fan and the connections in the switch housing. CAUTION: Make sure main power is off. Fan makes a noise while running: 1.
