Mahidra TUV 300 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
T4, T4+, T6, T6+, T6+ AMT, T8, T8 AMT
____________________________________________________________________________________
Original Issue Date: August 2015
Revision Date: September 2015
: Carefully read, understand and follow the instructions provided in this manual, and keep it in a safe place for future reference. If you have any
NOTE
doubt whatsoever regarding the use or care of your vehicle, please visit your Mahindra Dealer for assistance or advice.
This Owner's Manual should be considered as an integral part of the vehicle and should remain with the vehicle.
