 -20℃ ~ 80℃
 Humidity
 10% ~ 90% (Non-condensing)


Dimensions

IPC962-511 / IPC962-512
 147.5 mm (5.81") (W) x 192 mm (7.56") (H) x 230 mm (9.06") (D)
IPC964-512
 188.1 mm (7.39") (W) x 192 mm (7.54") (H) x 230 mm (9.04") (D) (IPC964-512)
Note: All specifications and images are subject to change without notice.
Note: The performance of the system might be adversely affected a t an operating
temperature above 60
Note: If the operating temperature is above 35
temperature SSD on the device.
1.3 Dimensions
The following diagrams show you dimensions and outlines of the IPC962-511-FL/IPC962-512-
FL/IPC964-512-FL Series.
IPC962-511 / IPC962-512
Introduction
°
C and un-recommended processor.
°
C
IPC962/IPC964 Series User's Manual
, it is recommended to use a wide
5
