Summary of Contents for Intermec Sabre 1400
- Page 1 Getting Started Guide Sabre 1400 Hand-held Scanner...
- Page 2 Introduction Connect scanner cable Use this Getting Started Guide to set up the Sabre 1400 for most terminal connections and symbologies. If necessary, use the EasySet setup software for additional configura- tion possibilities and terminal connections. Full setup Configuración completa Configuration complète...
- Page 3 Keyboard wedge (for PC) QWERTY Swedish / Finnish System power OFF QWERTY Italian QWERTY Norwegian Connect cables Din/mini-Din adaptor cable QWERTY Danish PC wedge cable P/N 3-604037-10 QWERTY Spanish power supply (normally not required) QWERTY Portuguese System power ON Customize parameters (optional) (*) = default value Select keyboard Postamble = Enter (*)
- Page 4 RS-232 C Customize parameters (optional) (*) = default value 9600 baud (*) System power OFF 19200 baud Connect cables 7 data bits (*) Standard RS-232 C cable P/N 3-604032-10 8 data bits Even parity (*) Scanner power ON Odd parity No parity System power ON Postamble = Carriage Return + Line Feed (*)
-
Page 5: Wand Emulation
Wand emulation cable UPC-A, UPC-E, EAN-8, EAN-13 P/N 3-606031-10 (UPC-A -> EAN-13) System power ON Code 128 / EAN 128 UPC-A, UPC-E, EAN-8, EAN-13 Wand emulation (UPC-A -> UPC-A) Digital wand emulation Analog wand emulation - Intermec interface, white high... -
Page 6: Default Setup
Test symbology Full setup with EasySet System power OFF Connect RS-232 C cable (P/N 3-604032-10) Scanner power ON System power ON Default setup EasySet setup Read this code Start EasySet software... -
Page 7: Operation
Operation Reading distance "beep" 2 cm - 30 cm (0.8" - 11.8") Typical average reading distance "beep" scanner stand P/N 068484... -
Page 8: Regulatory Statements
This device complies with UL 1950 standards. Cet équipement est conforme à la norme UL 1950. Intermec hereby declares that the Sabre 1400 has been tested and found compliant with the below listed standards as required by the EMC Directive 89/336/EEC as amended by 92/31/EEC and by the Low Voltage Directive 73/23/EEC as amended by 93/68/EEC: EN55022, EN55024, EN60950.
