Machine Control - Operating Elements - EWM Taurus 335 Basic S KGE Operating Instructions Manual

Machine description – quick overview
Machine control – Operating elements
4.2 Machine control – Operating elements
M 3.77
GMAW GMAW
MMA MMA
MMAG MMAG
1 1
8
Item Symbol Description
1
2
3
4
5
6
m/min
7
20
MIG / MAG MIG / MAG
E-HAND E-HAND
FUGENHOBELN FUGENHOBELN
AMP
Taurus Basic S
6
m/min
0
Button, welding process
MIG/MAG welding
GMAW MIG / MAG
MMA E-HAND
MMA welding
Air arc gouging
MMAG FUGENHOBELN
Wire inching button
See also "Inching the Wire Electrode" chapter
Gas test / rinse button
• Gas test: For setting the shielding gas quantity
• Rinse: For rinsing longer tube packages
See also "Shielding Gas Supply" chapter
Display, left
Welding current as actual value or hold value,
wire-feed speed as nominal value.
Display, right
Welding voltage
Rotary dial, wire speed
Wire speed setting
0.5 to 24 m/min
Rotary dial, welding voltage
Adjustment of the welding voltage from min. to max.
(twin-knob operation: wire speed/welding voltage)
4
5
7
9
DYN
- +
Figure 4-3
2
3
V
S
099-005214-EW501
19.05.2011
