EWM Taurus 335 Basic S KGE Operating Instructions Manual page 17

Item Symbol Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
099-005214-EW501
19.05.2011
Machine description – quick overview
0
Transport bar
Carrying handle
Cover for wire delivery unit and operating elements
Wire spool inspection window
Check wire supply
Slide latch, lock for the protective cap
Machine control
See Machine control – operating elements chapter
Cooling air inlet
Central connection for welding torch (Euro)
Integrated welding current, shielding gas and torch trigger
Machine feet
Park socket, polarity selection plug
Retainer for the polarity selection plug in MMA mode or for transport.
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, etc.)
Connection socket, "+" welding current
• MIG/MAG welding:
• MIG/MAG cored wire welding:
• MMA welding:
Connection socket, "-" welding current
• MIG/MAG welding:
• MIG/MAG cored wire welding:
• MMA welding:
Welding current cable, polarity selection
Welding current to the central connector/torch, enables polarity selection.
• MIG/MAG: Connection socket for "+" welding current
• Self-shielding cored wire
Protective cap (see Sect. "Protective cap")
welding current connection for the welding torch
workpiece connection
workpiece connection
workpiece connection
welding current connection for the welding torch
electrode holder connection
Taurus 335 Basic S
17
