Machine description – quick overview
0
Main switch, machine on/off
Connecting nipple G¼, shielding gas connection
4-pole connection socket
Cooling unit voltage supply
8-pole connection socket
Cooling unit control lead
Mains connection cable
19-pole interface for mechanised welding (analogue), optional
(see "Design and function" chapter)
Cooling air outlet
External wire feed inlet
Pre-cut casing inlet for external wire feed.
