4.2.1
Operating elements in the machine
Item
Symbol Description
1
2
3
42V/4A
4
COM
099-005214-EW501
19.05.2011
Machine description – quick overview
0
Operating mode changeover switch
Switching between non-latched and latched operating modes
Non-latched operation
Latched operation
Dynamics/choke effect button
+
Arc harder and narrower
-
Arc softer and wider
0
Wire spool retainer
Wire delivery unit
Key button, automatic cutout
Wire feed motor supply voltage fuse
press to reset a triggered fuse
PC interface, serial (D-Sub connection socket, 9-pole)
Machine control – Operating elements
Figure 4-4
