Removing The Component Bay Cover - EUROCOM m248 User Manual

Upgrading The Computer
6
Figure 6 - 2
Removing the
Component Bay
Cover

6 - 4 Removing the Component Bay Cover

Removing the Component Bay Cover
1. Turn off the computer, and turn it over and remove the battery (see page
2. Remove screws &
1
3. Slide the component bay cover until the cover and case indicators
4. Lift the bottom cover
3
from the bottom of the computer.
2
off the computer case.
4
1
2
6 - 3).
are aligned.
3
4
3
