Replacing The Hdd Bay Cover - EUROCOM m248 User Manual

Upgrading The Computer
Figure 6 - 5
Replacing the HDD
Bay Cover
6
6 - 8 Upgrading the Hard/Solid State Disk Drive

Replacing the HDD Bay Cover

1. Reinsert the HDD bay cover by placing it on the bottom case assembly, and make
sure the case markers line up
2. Apply downward pressure with both thumbs at points
in the direction of the arrows as illustrated.
3. Replace screws &
1
1
.
1
(Figure 6 - 4 on page 6 -
2
1
2
& and slide the cover
2 3
7) and battery (see page 6 -
3
3).
