EUROCOM m248 User Manual page 140

Upgrading The Computer
6
Figure 6 - 7
Component Bay -
SSD Removal
6 - 10 Upgrading the Hard/Solid State Disk Drive
Removing the SSD From the Component Bay
1. Remove the component bay cover (see page
2. The SSD slot is at point
3. Remove screw .
2
4. The SSD will pop-up and you can then remove it
3
5. Replace the SSD by angling it as illustrated, and then fit the connector firmly into
the slot.
6. The SSD module's pin alignment will allow it to only fit one way. Make sure the
module is seated as far into the slot as it will go. DO NOT FORCE the module; it
should fit without much pressure.
7. Press the SSD module down towards the mainboard and replace screw
the component bay cover.
1
6 -
on the mainboard.
1
2
4).
.
and
2
3
2
