Removing the Hard Disk Bay Cover

1. Turn off the computer, and turn it over and remove the battery (see page
2. Remove screws &
1
3. Slide the HDD bay cover in the direction of arrow
indicators are aligned.
4
4. Remove the HDD bay cover
1
2
5
from the bottom of the computer.
2
.
5
4
until the cover and case
3
4
3
Upgrading the Hard/Solid State Disk Drive 6 - 7
Upgrading The Computer
6 - 3).
Figure 6 - 4
Hard Disk Bay
Cover Removal
6
