7.3.1 Real-time Monitor

In section 2, left click the channel name you want to view, you can see the corresponding
video in current window.
On the top left corner, you can view device IP, channel number, network monitor bit stream.
On the top right corer, there are six unction buttons. See Figure 7-8.
•
1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in.
right click mouse system restores original status.
•
2: Change show mode: resize or switch to full screen mode.
•
3: Local record. When you click local record button, the system begins recording and
this button becomes highlighted. You can go to system folder RecordDownload to view
the recorded file.
•
4: Capture picture. You can snapshoot important video. All images are memorized in
system client folder \download\picture (default).
•
5: Audio :Turn on or off audio.(It has no relationship with system audio setup )
•
6: Close video.
Please refer to Figure 7-9 for main stream and extra stream switch information.
Open All
1 2 3
Figure 7-7
1 2 3 4 5 6
Figure 7-8
Figure 7-9
