PTZ interface is shown as in Figure 7-43.
Please note, before operation please make sure you have set speed dome address. And
DVR and speed dome connection is OK.
Please refer to the following sheet for detailed information.
Parameter Function
You can select monitor channel from the dropdown list. .
Channel
Select the corresponding dome protocol.(such as PELCOD)
Protocol
Set corresponding dome address. Default value is 1. Please note your
Address
setup here shall comply with your dome address; otherwise you can
not control the speed dome.
Baud Select the dome baud rate. Default setup is 9600.
Rate
Data Bit Default setup is 8. Please set according to the speed dome dial switch
setup.
Default setup is 1. Please set according to the speed dome dial switch
Stop bit
setup.
Parity Default setup is none. Please set according to the speed dome dial
switch setup.
Save You can click save button after you complete setup for one channel,
or you can complete the whole setups and then click save button.
Refresh Click this button to get device latest configuration information.
7.5.2.7 Default & Backup
Default: Restore factory default setup. You can select corresponding items.
Backup: Export current configuration to local PC or import configuration from current
PC. Please refer to Figure 7-44.
Please note system can not restore some information such as network IP address.
Figure 7-43
