Real-Time Monitor - ClearView N6 1U Series Quick Start Manual

—
Preview window switch. System support 1/4/8/9/16-window real-time preview. Please you
need to have the proper rights to implement preview operation. You can not preview if you
have no right to preview the either channel. See Figure 7-5. Please note this series device
does not support this function.
Section1
Section 2

7.3.1 Real-time Monitor

In section 2, left click the channel name you want to view, you can see the corresponding video
in current window.
On the top left corner, you can view device IP, channel number, network monitor bit stream.
On the top right corer, there are six unction buttons. See
Figure 7-5
Section 5
Figure 7-6
1 2 3
Figure 7-7
Figure 7-8
X434H434H434H
1 2 3 4 5 6
Section 3
Section 4
.
X
158
