Step: value ranges fro 1 to 8.
•
Zoom
•
Focus
•
Iris
Please click icon and
In Figure 4-30, please click direction arrows (See Figure 4-31) to adjust PTZ position. There
are total 8 direction arrows.
4.7.3 3D Intelligent Positioning Key
In the middle of the eight direction arrows, there is a 3D intelligent positioning key. See
Figure 4-32. Please make sure your protocol supports this function and you need to use
mouse to control.
Click this key, system goes back to the single screen mode. Drag the mouse in the screen
to adjust section size. The dragged zone supports 4X to 16X speeds. It can realize PTZ
automatically. The smaller zone you dragged, the higher the speed.
Here is a sheet for you reference.
Name Function
key
Zoom
Focus
Iris

4.8 Preset/ Patrol/Pattern/Scan

In Figure 4-30, please click the "set" button. The interface is shown as below. See Figure 4-33.
to adjust zoom, focus and iris.
Figure 4-30
Figure 4-31
Figure 4-32
function Shortcut
key
Near
�
│
Near
11⊳
close
Function function
key
Far
Far
Open
Shortcut
Key
�
►
│
11
