Please refer to the following sheet for detailed information.
SN Name
1 Video input
4 Audio input
7 USB port
10 Power socket
The 16-channel series product rear panel is shown as in Figure 2-4.
Please refer to the following sheet for detailed information.
SN Name
1 Video input
4 Audio input
7 USB port
10 Power socket
When connect the Ethernet port, please use crossover cable to connect the PC and use
the straight cable to connect to the switcher or router.

2.3 Connection Sample

The connection sample is shown as below. See Figure 2-5.
The following figure is based on the 4-channel series product.
Figure 2-3
SN Name
2 Video output
5 Video VGA output
8 Network port
11 On/off button
Figure 2-4
SN Name
2 Video output
5 Video VGA output
8 Network port
11 GND port
SN Name
3 Audio output
6 HDMI port
9 RS-485 input port
12 GND port
SN Name
3 Audio output
6 HDMI port
9 RS-485 input port
12 On/off button
