7.3.2.1 Direction key and 3D positioning key
In Figure 7-10, there are eight direction keys.
In the middle of the eight direction keys, there is a 3D intelligent positioning key.
Click 3D intelligent positioning key, system goes back to the single screen mode. Drag
the mouse in the screen to adjust section size. It can realize PTZ automatically.
7.3.2.2 Speed
System supports eight-level speed. You can select from the dropdown list. Speed 2 is faster
than speed 1.
7.3.2.3 Zoom/Focus/Iris
Here is a sheet for you reference.
Name
Zoom
Focus
Iris
In Figure 7-11, click PTZ setup button you can see the following interface. See Figure 7-12.
Figure 7-11
Function Function
key
Near
Near
close
3D Intelligent Positioning
Key
You can click this icon
to display or hide the
PTZ control platform.
Function Function
key
Far
Far
Open
