Parameter
Channel
Snapshot mode
Frame rate
Resolution
Quality
7.5.3.6 Abnormity
The abnormity interface is shown as below. See Figure 7-50.
Function
It is the monitor channel.
There are two modes: Timing and activation.
You can select from the dropdown list. The value ranges from
1f/s to 7f/s.
You can select from the dropdown list.
All-channel supports D1 resolution.
You can select from the dropdown list. Here is for you to set
video quality.
There are six options: 10％、30％、50％、60％、80％、
100％.
100% is the best quality.
Figure 7-50
