7.5.2.5 Detect
Analysis the video, system enable motion detection alarm when it detects the motion
signal reached the specified sensitivity.
The detection interface is shown as in Figure 7-41.
Please refer to the following sheet for detailed information.
Parameter Function
Event
There are three types: Motion detection/video loss/Camera Masking.
Type
Channel
Select channel name from the dropdown list.
Enable
You need to draw a circle to enable motion detection function.
There are six levels. The sixth level has the highest sensitivity.
Sensitivity
Figure 7-41
Figure 7-42
102
