ClearView Falcon-04E Series User Manual

Standalone dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Standalone DVR User's Manual
Standalone DVR User's Manual
V1.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Falcon-04E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ClearView Falcon-04E Series

Summary of Contents for ClearView Falcon-04E Series

  • Page 1 Standalone DVR User’s Manual Standalone DVR User’s Manual V1.0.0...

  • Page 2: Table Of Contents

    1.3.1 Falcon-04E Seires ......................2 1.3.2 Eagle-04/ Eagle-16 Series .................... 6 OVERVIEW AND CONTROLS ............... 11 Front Panel ........................11 2.1.1 Falcon-04E Series ....................... 11 2.1.2 Eagle-04/Eagle-16 Series ................... 11 Rear Panel ........................13 2.2.1 Falcon-04E Series ....................... 13 2.2.2 Eagle-04/Eagle-16 Series ...................
  • Page 3 Check Unpacked DVR ..................... 20 About Front Panel and Real Panel ................. 20 HDD Installation ....................... 20 3.3.1 Falcon-04E Series ....................... 20 3.3.2 Eagle-04/Eagle-16 Series ................... 21 Connecting Power Supply ....................22 Connecting Video Input and Output Devices ..............22 3.5.1...
  • Page 4 Standalone DVR User’s Manual Startup Wizard ........................28 Navigation Bar ........................31 4.3.1 Main Menu........................31 4.3.2 Output Screen ......................31 4.3.3 Favorites ........................31 4.3.4 Tour ..........................32 4.3.5 PTZ ..........................32 4.3.6 Color ..........................32 4.3.7 Search .......................... 32 4.3.8 Alarm Status .........................
  • Page 5 Standalone DVR User’s Manual 4.9.1 Search .......................... 63 4.9.2 Backup .......................... 71 4.9.3 Shut Down ........................73 4.10 Information ........................73 4.10.1 System Info ......................73 4.10.2 Event ........................77 4.10.3 Network ........................77 4.10.4 Log ........................... 80 4.11 Setting ..........................81 4.11.1 Camera ........................
  • Page 6 Standalone DVR User’s Manual 5.8.1 Camera ........................162 5.8.2 Network ........................169 5.8.3 Event........................... 185 5.8.4 Storage ........................193 5.8.5 System ........................197 Information ........................210 5.9.1 Version ........................210 5.9.2 Log ..........................210 5.9.3 Connection Log ......................211 5.9.4 Online User ........................
  • Page 7 Standalone DVR User’s Manual Appendix B-4 Compatible USB DVD List ................229 Appendix B-5 Compatible SATA DVD List ................229 Appendix B-6 Compatible SATA HDD List ................230 APPENDIX C COMPATIBLE CD/DVD BURNER LIST ......234 APPENDIX D COMPATIBLE DISPLAYER LIST ........235 APPENDIX E COMPATIBLE SWITCHER ...........
  • Page 8 Standalone DVR User’s Manual Welcome Thank you for purchasing our DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series standalone DVR features and functions. Before installation and operation please read the following safeguards and warnings carefully!

  • Page 9: Important Safeguards And Warnings

    Standalone DVR User’s Manual Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electric shock caused by improper handling or installation.

  • Page 10: Features And Specifications

    Standalone DVR User’s Manual FEATURES AND SPECIFICATIONS 1.1 Overview The standalone series DVR is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. It is easy to use and can realize surveillance function after some simple setups. It has various functions such as record, playback, monitor at the same time and can guarantee audio video synchronization.

  • Page 11: Specifications

    UPNP (Universal Plug and Play) Establish mapping connection between LAN and WAN via UPNP protocol. Slight function differences may be found due to different series. 1.3 Specifications 1.3.1 Falcon-04E Seires Falcon-04E Series Parameter High-performance industrial embedded micro controller Main System...
  • Page 12 Standalone DVR User’s Manual Interface User-friendly graphical user interface Input Front panel, USB mouse, remote control Devices Input Arabic number, English character, donation and extension Chinese Method (optional) Shortcut Copy/paste operation, USB mouse right-key shortcut menu, double click Function USB mouse to switch screen. Compression Video Standard...
  • Page 13 Standalone DVR User’s Manual Channel Channel name, recording status, screen lock status, video loss status and Information motion detection status are shown on the bottom left of display screen. Color Hue, brightness, contrast, saturation and gain setup for each channel. Configuratio Audio Hard Disk...
  • Page 14 Standalone DVR User’s Manual Network View alarm information such as external alarm, motion detection and Function video loss via client. Support network PTZ lens control File download backup and playback Multiple devices share information via corresponding software such as professional surveillance software (PSS) Support zero-channel encoding function Motion Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.

  • Page 15: Eagle-04/ Eagle-16 Series

    Standalone DVR User’s Manual Account lock strategy Five times login failure in thirty minutes may result in account lock. Upgrade Web browser, client-end and update tool. Password login protection to guarantee safety User-friendly interface when login. Provide the following options: Logout Login, Logout and Shutdown /shutdown/ restart.
  • Page 16 Standalone DVR User’s Manual 1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output. 1-ch VGA output. Video monitor 1-ch HDMI output. Video Output 1-ch matrix output 1-ch matrix output(Support multiple-window output mode) Support TV/VGA/HDMI video output at the same time. Video Support PAL/NTSC.
  • Page 17 Standalone DVR User’s Manual Hard Disk 2 built-in SATA port. Support 2 HDDs. Hard Disk Audio：PCM 28.8MByte/h Hard disk Occupation Video：56-900MByte/h Recording Manual recording, motion detection recording, schedule recording and Mode alarm recording Priority: Manual recording> alarm recording>motion detection Record recording>schedule recording.
  • Page 18 Standalone DVR User’s Manual Bidirectional audio. Motion Zone setup: support 396/330((PAL 22×18, NTSC 22×15)) detection Motion Detection zones. Detection and Various sensitivity levels. Alarm Alarm can activate record or external alarm or screen message prompt. Video Loss Alarm can activate external alarm or screen message prompt. External Alarm Support record activation function or activate external alarm or screen message in specified period.
  • Page 19 Standalone DVR User’s Manual Right authentication when shut down to make sure only those proper people can turn off DVR Power DC 12V Power ≤25W (With adapter, exclude HDD) General Consumption Parameter Working 0℃－＋55℃ Temperature Working 10%－90% Humidity Air Pressure 86kpa－106kpa Dimension 1U standard industrial case.

  • Page 20: Overview And Controls

    This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel 2.1.1 Falcon-04E Series The front panel is shown as below. See Figure 2-1. Figure 2-1 Please refer to the following sheet for detailed information.
  • Page 21 Standalone DVR User’s Manual In textbox, click this button to switch between numeral, Shift Shift English(Small/Capitalized),donation and etc. Activate current control, modify setup, and then move up and down. Up/1 、 Increase/decrease numeral. Down/4 Assistant function such as PTZ menu. In text mode, input number 1/4 (English character G/H/I) Shift current activated control, Left/2...

  • Page 22: Rear Panel

    Here you can view there is external alarm input or not. indication Alarm The light becomes on when there is an external alarm. The light light become off when the external alarm stops. 2.2 Rear Panel 2.2.1 Falcon-04E Series The rear panel is shown as below. See Figure 2-3.

  • Page 23: Eagle-04/Eagle-16 Series

    Standalone DVR User’s Manual Figure 2-3 Please refer to the following sheet for detailed information. Name Name Name Video input USB port Video VGA output GND port HDMI port Network port Power socket 2.2.2 Eagle-04/Eagle-16 Series Here we take the Eagle-16 rear panel as an example. See Figure 2-4. Figure 2-4 Please refer to the following sheet for detailed information.

  • Page 24: Connection Sample

    Standalone DVR User’s Manual Power input port Power button When connect the Ethernet port, please use crossover cable to connect the PC and use the straight cable to connect to the switch or router. 2.3 Connection Sample Please refer to Figure 2-5 for connection sample. The following figure is based on the Eagle-16 series product.
  • Page 25 Standalone DVR User’s Manual Figure 2-6 Serial Number Name Function Power button Click it to boot up or shut down the device. Address Click it to input device number, so that you can control it. Forward Various forward speeds normal speed playback. Slow play Multiple slow play speeds or normal playback.

  • Page 26: Mouse Control

    Standalone DVR User’s Manual click this button to realize normal playback. In reverse playback click this button to pause playback. Esc. Go back to previous menu or cancel current operation (close upper interface or control) Record Start or stop record manually In record interface, working with the direction buttons to select the record channel.
  • Page 27 Standalone DVR User’s Manual When you have selected one menu item, left click mouse to view menu content. Implement the control operation. Modify checkbox or motion detection status. Click combo box to pop up drop down list In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized).

  • Page 28: Virtual Keyboard & Front Panel

    Standalone DVR User’s Manual Right click In real-time monitor mode, pops up shortcut menu: one-window, mouse four-window, nine-window and sixteen-window, Pan/Tilt/Zoom, color setting, search, record, alarm input, alarm output, main menu. Among which, Pan/Tilt/Zoom and color setting applies for current selected channel.

  • Page 29: Installation And Connections

    Appendix for recommended HDD brand. All figures listed here for reference only. Please follow the instructions listed below to install hard disk. 3.3.1 Falcon-04E Series 1. Loosen the screws of the 2. Fix four screws in the HDD 3. Place the HDD in accordance with upper cover and side panel.

  • Page 30: Eagle-04/Eagle-16 Series

    Standalone DVR User’s Manual 4. Turn the device upside down 6. Connect the HDD cable and Fix the HDD firmly. and then turn the screws in power cable. firmly. in the chassis. 7. Put the cover in accordance Secure the screws in the with the clip and then place the rear panel and the side panel.

  • Page 31: Connecting Power Supply

    Standalone DVR User’s Manual 7. Put the cover in accordance Secure the screws in the with the clip and then place the rear panel and the side panel. upper cover back. Please note, when you install the HDD, please put the cable connecting the main board and the front panel at the proper position, otherwise it may result in device malfunction.

  • Page 32: Connecting Video Output

    Standalone DVR User’s Manual operation of the camera. Guarantee stability and reliability of the transmission line BTT TB Please use high quality, sound shielded BNC. Please select suitable BNC model according to the transmission distance. If the distance is too long, you should use twisted pair cable, and you can add video compensation devices or use optical fiber to ensure video quality.

  • Page 33: Alarm Input And Output Details

    Standalone DVR User’s Manual 1. Alarm input a. Please make sure alarm input mode is grounding alarm input. b. Grounding signal is needed for alarm input. c. Alarm input needs the low level voltage signal. d. Alarm input mode can be either NC (normal Open) or NO (Normal Close) e.

  • Page 34: Alarm Input Port

    Standalone DVR User’s Manual NO1 C1， There are three groups of normal open activation output (on/off NO2 C2， button) NO3 C3 Earth cable. 3.7.2 Alarm Input Port Please refer to the following sheet for more information.  Grounding alarm inputs. Normal open or Normal close type) ...

  • Page 35: Other Interfaces

    Standalone DVR User’s Manual Between touch and winding 1000VAC 1minute Between touches with same Surge voltage 1500V (10×160us) polarity Length of open 3ms max time Length of close 3ms max time Longevity Mechanical 50×106 times (3Hz) Electrical 200×103 times (0.5Hz) Temperature -40℃...

  • Page 36: Overview Of Navigation And Controls

    Standalone DVR User’s Manual 4 Overview of Navigation and Controls ALL FUNCTIONS LISTED BELOW FOR REFERENCE ONLY. YOUR PURCHASED PRODUCT MAY NOT SUPPORT ALL THE FUNCTIONS LISTED BELOW. 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure: ...

  • Page 37: Startup Wizard

    Standalone DVR User’s Manual 4.2 Startup Wizard After device successfully booted up, it goes to startup wizard. Click Cancel/Next button, you can see system goes to login interface. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time.
  • Page 38 Standalone DVR User’s Manual Note: For security reason, please modify password after you first login. Within 30 minutes, three times login failure will result in system alarm and five times login failure will result in account lock! Click OK button, you can go to General interface. See Figure 4-3. For detailed information, please refer to chapter 4.11.5.1.
  • Page 39 Standalone DVR User’s Manual Figure 4-4 Click Next button, you can go to Schedule interface. See Figure 4-5. For detailed information, please refer to chapter 4.11.4.1.1. Figure 4-5 Click Finish button, system pops up a dialogue box. Click the OK button, the startup wizard is complete.

  • Page 40: Navigation Bar

    Standalone DVR User’s Manual Figure 4-6 4.3 Navigation Bar You need to go to the Main menu->Setting->System->General to enable navigation bar function; otherwise you can not see the following interface. The navigation bar is shown as below. See Figure 4-7. Figure 4-7 4.3.1 Main Menu Click button...

  • Page 41: Tour

    Standalone DVR User’s Manual 4.3.4 Tour Click button to enable tour, the icon becomes , you can see the tour is in process. 4.3.5 PTZ Click , system goes to the PTZ control interface. Please refer to chapter 4.5. 4.3.6 Color Click button , system goes to the color interface.

  • Page 42: Network

    Standalone DVR User’s Manual 4.3.11 Network Click , system goes to the network interface. It is to set network IP address, default gateway and etc. Please refer to chapter 4.11.2. 4.3.12 HDD Manager ， system goes to the HDD manager interface. It is to view and manage HDD Click information.

  • Page 43: Preview Control Interface

    Standalone DVR User’s Manual Recording status Video loss Motion detection Camera lock Tips  Preview drag: If you want to change position of channel 1 and channel 2 when you are previewing, you can left click mouse in the channel 1 and then drag to channel 2, release mouse you can switch channel 1 and channel 2 positions.
  • Page 44 Standalone DVR User’s Manual Figure 4-13  Put the middle button at the centre of the zone you want to zoom in, and move the mouse, you can view an interface shown as in Figure 4-14. Figure 4-14 Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device.

  • Page 45: Right Click Menu

    Standalone DVR User’s Manual Remote device (For digital channel only) Shortcut menu. Click it to go to the remote device interface to add/delete remote device or view its corresponding information. Please refer to chapter 4.11.1.1 for detailed information. 4.4.3 Right Click Menu After you logged in the device, right click mouse, you can see the short cut menu.
  • Page 46 Standalone DVR User’s Manual Figure 4-16 Please refer to the following sheet for detailed information. Item Note Period There are two periods in one day. You can set different sharpness, brightness, and contrast setup for different periods. Effective Time Check the box here to enable this function and then set period time.

  • Page 47: Ptz

    Standalone DVR User’s Manual Item Note become hazy if the value is too low. If this value is too high, the dark section may lack brightness while the bright section may over exposure .The recommended value ranges from 40 to 60. Saturation It is to adjust monitor window saturation.
  • Page 48 Standalone DVR User’s Manual  PTZ type: There are two types: local/remote. Please select local mode if you are connect RS485 cable to connect to the Speed dome (PTZ). Please select remote mode if you are connecting to the network PTZ camera. ...

  • Page 49: Ptz Control

    Standalone DVR User’s Manual Figure 4-18 4.5.2 PTZ Control After completing all the setting please click save button. Right click mouse (click “Fn” Button in the front panel or click “Fn” key in the remote control). The interface is shown as in Figure 4-19.
  • Page 50 Standalone DVR User’s Manual Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc. Speed is to control PTZ movement speed. The value ranges from 1 to 8.The speed 8 is faster than speed 1.
  • Page 51 Standalone DVR User’s Manual Figure 4-22 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 4-20.
  • Page 52 Standalone DVR User’s Manual Figure 4-23 Preset Setup In Figure 4-23, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 4-24. Click Set button and then input preset number. Click Set button to save current preset.
  • Page 53 Standalone DVR User’s Manual Figure 4-25 Pattern Setup In Figure 4-23, click Pattern button and input pattern number. Click Begin button to start direction operation. Or you can go back to Figure 4-20 to operate zoom/focus/iris/direction operation. In Figure 4-23, click End button. Figure 4-26 Scan Setup In Figure 4-23, click Scan button.
  • Page 54 Standalone DVR User’s Manual Figure 4-27 4.5.2.2 Call PTZ Function Call Preset In Figure 4-22, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-22, input pattern value and then click to call a pattern.

  • Page 55: Record And Snapshot

    Standalone DVR User’s Manual Click , system goes to the following interface. The options here are defined by the protocol. The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-28. Figure 4-28 4.6 Record and Snapshot The record/snapshot priority is: Alarm->Motion detect->Schedule.
  • Page 56 Standalone DVR User’s Manual same encode setup for all channels. Audio/video enable box, overlay button and the copy button is shield. Please highlight icon to select the corresponding function. Figure 4-29 4.6.1.2 Overlay Click overlay button, you can see an interface is shown in Figure 4-30. ...
  • Page 57 Standalone DVR User’s Manual Figure 4-30 4.6.1.3 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-82.  Snapshot mode: There are two modes: regular and trigger. If you set regular mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation.

  • Page 58: Schedule

    Standalone DVR User’s Manual Figure 4-32 4.6.2 Schedule The record type priority is: Alarm>Motion detect>Regular. 4.6.2.1 Schedule Record Set record time, record plan and etc. Please note system is in 24-hour record by default after its first boot up. In the main menu, from Main menu->Setting->Storage->Schedule, you can go to schedule menu.
  • Page 59 Standalone DVR User’s Manual  Period setup: Click button after one date or a holiday, you can see an interface shown as in Figure 4-37.There are four record types: regular, motion detection (MD), Alarm, MD & alarm. Please following the steps listed below to draw the period manually. Select a channel you want to set.
  • Page 60 Standalone DVR User’s Manual Figure 4-36 Figure 4-37 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-38. You can see current channel name is grey such as channel 1.
  • Page 61 Standalone DVR User’s Manual Figure 4-38 Click OK button to save current setup. 4.6.2.2 Schedule Snapshot From Main menu->Setting->Storage->Record or on the preview interface, right click mouse and then select record item, you can see Figure 4-39. Select snapshot channel and enable snapshot function. Click Save button. Figure 4-39 From Main menu->Setting->Camera->Encode->Snapshot, you can go to snapshot interface.
  • Page 62 Standalone DVR User’s Manual Figure 4-40 In the main menu, from Main menu->Setting->Storage->Schedule, you can go to schedule menu. See Figure 4-128. Here you can set snapshot period. There are total six periods in one day. Please refer to chapter 4.6.2.1 for detailed setup information. The setup steps are general the same.

  • Page 63: Motion Detect Record/Snapshot

    Standalone DVR User’s Manual have enabled these two types at the same time, system can activate the trigger snapshot when an alarm occurs, and otherwise system just operates the regular snapshot.  Only the trigger snapshot supports this function. The regular snapshot function can not send out picture via the email.
  • Page 64 Standalone DVR User’s Manual are two ways for you to set periods. Please note system only supports 6 periods in one day.  In Figure 4-110, Select icon of several dates, all checked items can be edited together. Now the icon is shown as .
  • Page 65 Standalone DVR User’s Manual Figure 4-44 4.6.3.2 Motion Detect Snapshot From Main menu->Setting->Camera->Encode->Snapshot, you can go to snapshot interface. See Figure 4-45. In Figure 4-45, select trigger snapshot from the dropdown list and then set picture size, quality and snapshot frequency. Click OK button to save current setup.

  • Page 66: Alarm Record/Snapshot

    Standalone DVR User’s Manual Figure 4-45 4.6.4 Alarm Record/Snapshot 4.6.4.1 Alarm Record Before you set alarm setup information, please connect alarm input and alarm output cable (such as light, siren and etc). The record priority is: Alarm>Motion detect>Regular. In the main menu, from Setting->Event-> Alarm, you can see alarm setup interface. See Figure 4-46.
  • Page 67 Standalone DVR User’s Manual Figure 4-46 From Mani menu->Setting->Storage->Schedule, you can go to Figure 4-128. Select alarm channel, period and the record type shall be alarm. Please refer to chapter 4.6.2. Click Copy button to copy current setup to other channel(s). Click OK button to save alarm record information.

  • Page 68: Manual Record/Snapshot

    Standalone DVR User’s Manual Figure 4-47 4.6.5 Manual Record/Snapshot You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. 4.6.5.1 Manual Record Right click mouse and select manual record or in the main menu, from Setting->Storage->Manual Record.

  • Page 69: Holiday Record/Snapshot

    Standalone DVR User’s Manual Figure 4-48 Check the box here to select manual record channel(s). You can see the corresponding indicator light on the front panel is on.  Channel: It is to display device all channels.  Manual: It has the highest priority. Enable corresponding channel to record no matter what period applied in the record setup.
  • Page 70 Standalone DVR User’s Manual interface. See Figure 4-49. Figure 4-49 Click Add new holiday button, you can see an interface shown as in Figure 4-50. Here you can set holiday date name, repeat mode, start time/end time and etc. Figure 4-50 Click Add button to complete holiday setup.

  • Page 71: Other Record/Snapshot

    Standalone DVR User’s Manual See Figure 4-51. Now you can set period and record type of holiday time. Please refer to chapter 4.6.2.1 for detailed setup information. Figure 4-51 Click OK button to set holiday record setup. 4.6.6.2 Holiday Snapshot Set Holiday date first.

  • Page 72: Main Menu

    Standalone DVR User’s Manual and chapter 4.11.5.11 for detailed information. Figure 4-52 4.8 Main Menu The main menu interface is shown as below. See Figure 4-53. Figure 4-53 4.9 Operation 4.9.1 Search...
  • Page 73 Standalone DVR User’s Manual Click search button in the main menu, search interface is shown as below. See Figure 4-54. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file Figure 4-54 Please refer to the following sheet for more information.
  • Page 74 Standalone DVR User’s Manual HDD if there are pictures on the redundancy HDD.  The blue highlighted date means there is picture or file. Otherwise, there is no picture or file. Calendar  In any play mode, click the date you want to see, you can see the corresponding record file trace in the time bar.
  • Page 75 Standalone DVR User’s Manual In slow play mode, click it to switch between play/pause. ■ Stop Backward play In normal play mode, left click the button, the file begins backward play.  Click it again to pause current play. In backward play mode, click ►/ to restore normal play. In playback mode, click it to play the next or the previous section.
  • Page 76 Standalone DVR User’s Manual ●The option includes: 24H, 12H, 1H and 30M. The smaller the unit, the larger the zoom rate. You can accurately set the time in the time bar to playback the record. Time bar  The time bar is beginning with 0 o'clock when you are setting the configuration. unit The time bar zooms in the period of the current playback time when you are playing the file.
  • Page 77 Standalone DVR User’s Manual channel period of the corresponding channel to play. synchroni zation switch to play when playback When the system is in full-screen playback mode, left click the mouse in the Digital screen. Drag your mouse in the screen to select a section and then left click zoom mouse to realize digital zoom.
  • Page 78 Standalone DVR User’s Manual  System does not support motion detect zone setup during the full-screen mode.  During the multiple-channel playback, system stops playback of rest channels if you implement one-channel smart search. 4.9.1.2 Accurate playback by time Select records from one day, click the list, you can go to the file list interface. You can input time at the top right corner to search records by time.
  • Page 79 Standalone DVR User’s Manual Figure 4-57  Playback Mark During 1-window playback mode, click mark file list button in Figure 4-54, you can go to mark file list interface. Double click one mark file, you can begin playback from the mark time.

  • Page 80: Backup

    Standalone DVR User’s Manual  Modify Double click one mark information item, you can see system pops up a dialogue box for you to change mark information. You can only change mark name here.  Delete Here you can check the mark information item you want to delete and then click Delete button, you can remove one mark item.
  • Page 81 Standalone DVR User’s Manual Figure 4-60 √ before channel name. You can use Fn or cancel System only backup files with a button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button.

  • Page 82: Shut Down

    Standalone DVR User’s Manual When the system completes backup, you can see a dialogue box prompting successful backup.  File format: Click the file format; you can see there are two options: DAV/ASF. The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S.
  • Page 83 Standalone DVR User’s Manual Figure 4-63 4.10.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-64.  SATA: 1-8 here means system max supports 8 HDDS. ○ means current HDD is normal.
  • Page 84 Standalone DVR User’s Manual Figure 4-64 Double click one HDD information; you can see the HDD SMART information. See Figure 4-65. Figure 4-65 4.10.1.2 Record Info It is to view record start time and end time. See Figure 4-66.
  • Page 85 Standalone DVR User’s Manual Figure 4-66 4.10.1.3 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 4-67. Figure 4-67 4.10.1.4 Version Here is for you to view some version information such as version number, built date, serial number and etc.

  • Page 86: Event

    Standalone DVR User’s Manual Figure 4-68 4.10.2 Event It is to display device status and channel status. See Figure 4-69. Figure 4-69 4.10.3 Network 4.10.3.1 Online Users...
  • Page 87 Standalone DVR User’s Manual Here is for you to manage online users. See Figure 4-70. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.
  • Page 88 Standalone DVR User’s Manual Figure 4-71 4.10.3.3 Network Test Network test interface is shown as in Figure 4-72.  Destination IP: Please input valid IPV4 address or domain name.  Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc.

  • Page 89: Log

    Standalone DVR User’s Manual Figure 4-72 4.10.4 Log Here is for you to view system log file. System lists the following information. See Figure 4-73. Log types include system operation, configuration operation, data management, alarm event, record operation, account manager, log clear, file operation and etc. It optimized reboot log.

  • Page 90: Setting

    Standalone DVR User’s Manual Figure 4-73 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc. See Figure 4-74.
  • Page 91 Standalone DVR User’s Manual 4-75. Here you can add/delete remote device and view its corresponding information.  IP search: Click it to search IP address. It includes device IP address, port, device name, manufacturer, type. Use your mouse to click the item name, you can refresh display order.
  • Page 92 Standalone DVR User’s Manual Click the Manual Add button; you can go to the following interface. See Figure 4-76. Channel number：The dropdown list here displays unconnected channel number. You can go to Figure 4-75 to set remote channel connection. Please note: ...
  • Page 93 Standalone DVR User’s Manual Figure 4-77 4.11.1.1.3 Firmware It is to view channel, IP address, manufacturer, type, system version, SN, video input, audio input, and etc. See Figure 4-78. Figure 4-78 4.11.1.2 Camera...
  • Page 94 Standalone DVR User’s Manual For analog channel, the camera interface is shown as in Figure 4-79. For digital channel, the camera interface is shown as in Figure 4-80.  Channel: Select a channel from the dropdown list.  Saturation: It is to adjust monitor window saturation. The value ranges from 0 to 100. The default value is 50.
  • Page 95 Standalone DVR User’s Manual  Auto: The auto white balance is on. System can auto compensate the color temperature to make sure the vide color is proper.  Sunny: The threshold of the white balance is in the sunny mode. ...
  • Page 96 Standalone DVR User’s Manual Figure 4-80 4.11.1.3 Encode It is to set video bit stream, picture bit stream, video overlay param eter and etc. 4.11.1.3.1 Video Video setting includes the following items. See Figure 4-81.  Channel: Select the channel you want. ...
  • Page 97 Standalone DVR User’s Manual Figure 4-81 4.11.1.3.2 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-82.  Snapshot mode: There are two modes: regular and trigger. If you set timing mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation.
  • Page 98 Standalone DVR User’s Manual Figure 4-82 4.11.1.3.3 Overlay Overlay interface is shown as in Figure 4-83.  Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel. ...
  • Page 99 Standalone DVR User’s Manual Figure 4-83 Figure 4-84 4.11.1.3.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-85.
  • Page 100 Standalone DVR User’s Manual Figure 4-85 4.11.1.3.5 Channel Type This function is for some series only. This function is for some series only. Please refer to Appendix G for detailed information. It is to set channel type. Each channel supports analog standard definition connections/analog HD connection/network camera connection (Slight function difference may be found).

  • Page 101: Network

    Standalone DVR User’s Manual 4.11.2 Network 4.11.2.1 TCP/IP The single network adapter interface is shown as in Figure 4-87 and the dual network adapters interface is shown as in Figure 4-88  Network Mode : Includes multiple access, fault tolerance, and load balancing ...
  • Page 102 Standalone DVR User’s Manual  MTU: It is to set MTU value of the network adapter. The value ranges from 1280-7200 bytes. The default setup is 1500 bytes. Please note MTU modification may result in network adapter reboot and network becomes off. That is to say, MTU modification can affect current network service.
  • Page 103 Standalone DVR User’s Manual Figure 4-88 4.11.2.2 Connection The connection setup interface is shown as in Figure 4-89.  Max connection: system support maximal 128 users. 0 means there is no connection limit.  TCP port: Default value is 37777. ...
  • Page 104 Standalone DVR User’s Manual Figure 4-89 4.11.2.3 WIFI The WIFI interface is shown as below. See Figure 4-90.  Auto connect WIFI: Check the box here, system automatically connects to the previous WIFI hotspot.  Refresh: You can click it to search the hotspot list again. It can automatically add the information such as the password if you have set it before.
  • Page 105 Standalone DVR User’s Manual Figure 4-90  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
  • Page 106 Standalone DVR User’s Manual  Dial number: Please input 3G network dialup number you got from your ISP.  User name: It is the user name for you to login the 3G network.  Password: It is the password for you to login the 3G network. ...
  • Page 107 Standalone DVR User’s Manual Figure 4-92 4.11.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-93. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
  • Page 108 Standalone DVR User’s Manual Figure 4-93 Please note NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
  • Page 109 Standalone DVR User’s Manual  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP.
  • Page 110 Standalone DVR User’s Manual  Default: Click it to restore default setup. In this case, the trusted sites and blocked sites are both null. Note:  If you enabled trusted sites, only the IP in the trusted sites list can access the device. ...
  • Page 111 Standalone DVR User’s Manual  Title: Please input email subject here. System support English character and Arabic number. Max 32-digit.  Receiver: Please input receiver email address here. System max supports 3 email boxes. System automatically filters same addresses if you input one receiver repeatedly.
  • Page 112 Standalone DVR User’s Manual -> Serv-U Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user. See Figure 4-97. Figure 4-97 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify...
  • Page 113 Standalone DVR User’s Manual After completed channel and weekday setup, you can set two periods for one each channel. Click the Test button, you can see the corresponding dialogue box to see the FTP connection is OK or not. Figure 4-99 4.11.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN.
  • Page 114 Standalone DVR User’s Manual Important: When you are setting the router external port, please use 1024~5000 port. Do not use well-known port 1~255 and the system port 256~1023 to avoid conflict. For the TCP and UDP, please make sure the internal port and external port are the same to guarantee the proper data transmission.
  • Page 115 Standalone DVR User’s Manual You can set in the following interface. See Figure 4-102. Figure 4-102 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, DVR-SNMP-MIB) to connect to the device.
  • Page 116 Standalone DVR User’s Manual Figure 4-103 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110” ...
  • Page 117 Standalone DVR User’s Manual Multiple cast IP: 235.8.8.36 Multiple cast PORT: 3666. After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only.
  • Page 118 Standalone DVR User’s Manual Important The server IP address can also be domain. But you need to register a domain name before you run proxy device server. 4.11.2.14 Alarm Centre This interface is reserved for you to develop. See Figure 4-105. Figure 4-105 4.11.2.15 P2P The P2P interface is shown as in Figure 4-106.

  • Page 119: Event

    Standalone DVR User’s Manual 4.11.3 Event 4.11.3.1 Detect In the main menu, from Setting->Event->Detect, you can see motion detect interface. See Figure 4-107.There is three detection types: motion detection, video loss, tampering.  The video loss has no detection region and sensitivity setup and tampering has no detection region setup.
  • Page 120 Standalone DVR User’s Manual specified periods. It is not for video loss or the tampering. There are two ways for you to set periods. Please note system only supports 6 periods in one day.  In Figure 4-110, Select icon of several dates, all checked items can be edited together.
  • Page 121 Standalone DVR User’s Manual In Figure 4-108, you can left click mouse and then drag it to set a region for motion detection. Click Fn to switch between arm/withdraw motion detection. After setting, click enter button to exit. Figure 4-107 Figure 4-108...
  • Page 122 Standalone DVR User’s Manual Figure 4-109 Figure 4-110...
  • Page 123 Standalone DVR User’s Manual Figure 4-111 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.11.3.1.2 Video Loss In Figure 4-107, select video loss from the type list. You can see the interface is shown as in Figure 4-112.This function allows you to be informed when video loss phenomenon occurred.
  • Page 124 Standalone DVR User’s Manual Figure 4-112 4.11.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-113. You can enable “Alarm output “or “Show message”...
  • Page 125 Standalone DVR User’s Manual Figure 4-113 4.11.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. For analog channel, there are two alarm types. See Figure 4-114 to Figure 4-115. For digital channel, there are four alarm types.
  • Page 126 Standalone DVR User’s Manual are two ways for you to set periods. There are max 6 periods in one day. There are four record types: regular, motion detection (MD), Alarm, MD & alarm.  In Figure 4-119, Select icon of several dates, all checked items can be edited together.
  • Page 127 Standalone DVR User’s Manual activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.  Video matrix: Check the box here to enable this function. When an alarm occurs, SPOT OUT port displays device video output. It displays video (1-window tour) from alarm activation channel you select at the Record channel item.
  • Page 128 Standalone DVR User’s Manual Figure 4-115 Figure 4-116...
  • Page 129 Standalone DVR User’s Manual Figure 4-117 Figure 4-118...
  • Page 130 Standalone DVR User’s Manual Figure 4-119 Figure 4-120 4.11.3.3 Abnormality There are two types: HDD/Network.  HDD: HDD error, no disk, no space. See Figure 4-121 and Figure 4-122.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-123.  Alarm output: Please select alarm activation output port (multiple choices).
  • Page 131 Standalone DVR User’s Manual  Latch: Here you can set corresponding delaying time. The value ranges from 1s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.  Show message: system can pop up the message in the local screen to alert you when alarm occurs.
  • Page 132 Standalone DVR User’s Manual Figure 4-122 Figure 4-123 4.11.3.4 Alarm Output Here is for you to set proper alarm output such as schedule, manual. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-124.

  • Page 133: Storage

    Standalone DVR User’s Manual Figure 4-124 4.11.4 Storage 4.11.4.1 Schedule 4.11.4.1.1 Record Note: You need to have proper rights to implement the following operations. Please mak e sure the HDDs have been properly installed. After the system booted up, it is in default 24-hour regular mode. You can set record type and time in schedule interface.
  • Page 134 Standalone DVR User’s Manual  Holiday: It is to set holiday setup. Please note you need to go to the General interface (Main Menu->System->General) to add holiday first. Otherwise you can not see this item.  Pre-record: System can pre-record the video before the event occurs into the file. The value ranges from 1 to 30 seconds depending on the bit stream.
  • Page 135 Standalone DVR User’s Manual Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording.
  • Page 136 Standalone DVR User’s Manual 4.11.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-130. You can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.
  • Page 137 Standalone DVR User’s Manual 4.11.4.1.2 Snapshot 4.11.4.1.2.1 Schedule Snapshot  On the preview interface, right click mouse and then select Manual->Record, or in the main menu, from Setting->Storage->Record, check the box to enable snapshot function of corresponding channels. See Figure 4-131. ...
  • Page 138 Standalone DVR User’s Manual Figure 4-132 Figure 4-133 4.11.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.
  • Page 139 Standalone DVR User’s Manual  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency. See Figure 4-134.  In main menu, from Setting->Event->Detect, please enable snapshot function for specified channels (Figure 4-135). Or In main menu, from Setting->Event->Alarm (Figure 4-136) please enable snapshot function for specified channels.
  • Page 140 Standalone DVR User’s Manual Figure 4-136 4.11.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
  • Page 141 Standalone DVR User’s Manual Please input corresponding information here, if you just upload the image FTP. Figure 4-137 4.11.4.2 HDD Manager Here is for you to view and implement hard disk management. See Figure 4-138. You can see current HDD type, status, capacity and etc. The operation includes format HDD, and change HDD property (read and write/read-only/redundancy).
  • Page 142 Standalone DVR User’s Manual 4.11.4.3.1 Record Control Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu. ...

  • Page 143: System

    Standalone DVR User’s Manual Figure 4-140 Tips You can check All button after the corresponding status to enable/disable all-channel snapshot function. 4.11.5 System 4.11.5.1 General 4.11.5.1.1 Device General setting includes the following items. See Figure 4-141.  Device ID: Please input a corresponding device name here. ...
  • Page 144 Standalone DVR User’s Manual  Auto logout: Here is for you to set auto logout interval once login user remains inactive for a specified time. Value ranges from 0 to 60 minutes.  Navigation bar: Check the box here, system displays the navigation bar on the interface.
  • Page 145 Standalone DVR User’s Manual Figure 4-142 4.11.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-143. Click Add new holiday button, you can input new holiday information. See Figure 4-144. Here you can set holiday name, repeat mode and start/end time. Note ...
  • Page 146 Standalone DVR User’s Manual Figure 4-143 Figure 4-144 4.11.5.2 Display 4.11.5.2.1 Display Display setup interface is shown as below. See Figure 4-145.  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.
  • Page 147 Standalone DVR User’s Manual  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end. You need to open web or client end to refresh channel name.
  • Page 148 Standalone DVR User’s Manual Figure 4-146 4.11.5.2.3 Tour Here you can activate tour function. Click Setup button, you can see an interface shown as in Figure 4-147  Enable tour: Highlight box here to enable this function.  Interval: System supports 1/8/-window tour. Input proper interval value here. The value ranges from 5-120 seconds.
  • Page 149 Standalone DVR User’s Manual Figure 4-147 4.11.5.2.4 Zero-channel Encoding Click zero-channel encoding button, you can go to the following interface. See Figure 4-148. Here you can enable and set zero-channel encoding function so that you can view several video sources at one channel. ...
  • Page 150 Standalone DVR User’s Manual Figure 4-148 4.11.5.2.5 Favorites It is for you to set and save favorites preview setup. You can select different window display modes and then select corresponding channel(s). Please note for one mode, one channel can only be selected once. See Figure 4-149. ...
  • Page 151 Standalone DVR User’s Manual Figure 4-149 On the navigation bar, you can see the Favorites shortcut menu. You can select from the dropdown list. Click View 1, you can see the channel(s) you saved on the Favorites folder. See Figure 4-150. Figure 4-150 4.11.5.3 Video Matrix Here you can set matrix output channel and its interval.
  • Page 152 Standalone DVR User’s Manual Figure 4-151 4.11.5.4 RS232 RS232 interface is shown as below. There are five items. See Figure 4-152.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboard is for you to control the device via the special keyboard.
  • Page 153 Standalone DVR User’s Manual Figure 4-152 4.11.5.5 PTZ The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 4-153.  Control mode: You can select control mode from the dropdown list. There are two options: Serial/HDCVI. For HDCVI series product, please select HDCVI. The control signal is sent to the PTZ via the coaxial cable.
  • Page 154 Standalone DVR User’s Manual Figure 4-153 4.11.5.6 ATM/POS The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode includes COM and network. 4.11.5.6.1 COM Type The COM interface is shown as below. See Figure 4-154. ...
  • Page 155 Standalone DVR User’s Manual Figure 4-154 4.11.5.6.2 Network Type The network type interface is shown as below. See Figure 4-155. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements. With the protocol For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number).
  • Page 156 Standalone DVR User’s Manual Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-156. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
  • Page 157 Standalone DVR User’s Manual 4.11.5.7 Account Here is for you to implement account management. See Figure 4-158 and Figure 4-159. Here you can:  Add new user  Modify user  Add group  Modify group  Modify password. For account management please note: ...
  • Page 158 Standalone DVR User’s Manual Figure 4-158 Figure 4-159 4.11.5.7.1 Add/Modify Group Click add group button in Figure 4-159 , the interface is shown as below. See Figure 4-160. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback,...
  • Page 159 Standalone DVR User’s Manual record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc. The modify group interface is similar to the Figure 4-160. Figure 4-160 4.11.5.7.2 Add/Modify User Click add user button in Figure 4-158 , the interface is shown as in Figure 4-161.
  • Page 160 Standalone DVR User’s Manual Figure 4-161 When you create a new user, you can input the corresponding MAC address of current user. If you leave this item in blank, any MAC address user can share this user account to login. Please note system needs to check the validity of MAC. Only the 12-digit 0-f format address can pass the validity verification.
  • Page 161 Standalone DVR User’s Manual Figure 4-162 4.11.5.9 Config Backup The configuration file backup interface is shown as below. See Figure 4-163. This function allows you to import/export system configuration. You can use this function when there are several devices need the same setup. ...
  • Page 162 Standalone DVR User’s Manual Figure 4-163 4.11.5.10 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup. See Figure 4-164.  Camera  Network  Event  Storage  System Please highlight icon to select the corresponding function.
  • Page 163 Standalone DVR User’s Manual Figure 4-164 4.11.5.11 Upgrade Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-165.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update.

  • Page 164: Web Operation

    Standalone DVR User’s Manual 5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...

  • Page 165: Lan Mode

    Standalone DVR User’s Manual Figure 5-2 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-3. Figure 5-3 This main window can be divided into the following sections.  Section 1: there are five function buttons: Live（chapter 5.4）, setup (chapter 5.8), search (chapter 5.10), alarm (chapter 5.11), and logout (chapter 5.12).
  • Page 166 Standalone DVR User’s Manual  Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 5-4. Figure 5-4 Please refer to Figure 5-5 for main stream and extra stream switch information. Figure 5-5 ...

  • Page 167: Real-Time Monitor

    Standalone DVR User’s Manual Figure 5-8  Section 6: From the left to the right ,you can see video quality/fluency/ full screen/1-window/4-window/6-window/8-window/9-window/13-window/16-window/20- window/25-window/36-window.. You can set video fluency and real-time feature priority.  Section 7: PTZ operation panel. Please refer to chapter 5.5 for detailed information. ...

  • Page 168: Ptz

    Standalone DVR User’s Manual  1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.  2: Local record. When you click local record button, the system begins recording and this button becomes highlighted.

  • Page 169: Image/Relay-Out

    Standalone DVR User’s Manual Parameter Function You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-11 5.6 Image/Relay-out Select one monitor channel video and then click Image button in section 8, the interface is shown as Figure 5-12.

  • Page 170: Wan Login

    Standalone DVR User’s Manual Figure 5-13 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-14. Figure 5-14 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.

  • Page 171: Setup

    Standalone DVR User’s Manual Figure 5-15 Important The window display mode and the channel number are by default. For example, for the 16-channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
  • Page 172 Standalone DVR User’s Manual Figure 5-16 Figure 5-17 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type.
  • Page 173 Standalone DVR User’s Manual Parameter Function Delete Click , you can delete the remote connection of the corresponding channel. : Connection succeeded. Connection status : Connection failed. Delete Select a device in the Added device list and then click Delete button, system can disconnect the device and remove it from the Added device list.
  • Page 174 Standalone DVR User’s Manual Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods. It is to adjust monitor video brightness and darkness level. The default value is 50. The bigger the value is, the large the contrast between the bright and dark section is and vice versa.
  • Page 175 Standalone DVR User’s Manual Figure 5-19 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Video enable Check the box here to enable extra stream video. This item is enabled by default.
  • Page 176 Standalone DVR User’s Manual VBR mode. Reference bit Recommended bit rate value according to the resolution and rate frame rate you have set. I Frame Here you can set the P frame amount between two I frames. The value ranges from 1 to 150. Default value is 50. Recommended value is frame rate *2.
  • Page 177 Standalone DVR User’s Manual Figure 5-21 Please refer to the following sheet for detailed information. Parameter Function Cover-area Check Preview or Monitor first. Click Set button, you can privacy mask the specified video in the preview or monitor video. System max supports 4 privacy mask zones. Time Title You can enable this function so that system overlays time information in video window.

  • Page 178: Network

    Standalone DVR User’s Manual Figure 5-22 5.8.1.4 Channel Name Here you can set channel name. See Figure 5-23. Figure 5-23 5.8.2 Network 5.8.2.1 TCP/IP The TCP/IP interface is shown as in Figure 5-24. Figure 5-24 Please refer to the following sheet for detailed information. Parameter Function Mode...
  • Page 179 Standalone DVR User’s Manual DHCP mode to auto search the IP.  If you select the static mode, you need to set the IP/submask/gateway manually.  If you select the DHCP mode, you can view the IP/submask/gateway from the DHCP. ...
  • Page 180 Standalone DVR User’s Manual Figure 5-26 Please refer to the following sheet for detailed information. Parameter Function Max connection It is the max Web connection for the same device. The value ranges from 1 to 120. The default setup is 120. TCP port The default value is 37777.
  • Page 181 Standalone DVR User’s Manual Please check the box to enable WIFI function and then click the Search SSID button. Now you can view all the wireless network information in the following list. Double click a name to connect to it. Click Refresh button, you can view latest connection status. 5.8.2.5 3G 5.8.2.5.1 CDMA/GPRS The CDMA/GPRS interface is shown as in Figure 5-28.
  • Page 182 Standalone DVR User’s Manual Figure 5-29 5.8.2.6 PPPoE The PPPoE interface is shown as in Figure 5-30. Input the PPPoE user name and password you get from the IPS (internet service provider) and enable PPPoE function. Please save current setup and then reboot the device to get the setup activated.
  • Page 183 Standalone DVR User’s Manual Figure 5-31 Please refer to the following sheet for detailed information. Parameter Function Server Type You can select DDNS protocol from the dropdown list and then enable DDNS function. Server IP DDNS server IP address Server Port DDNS server port.
  • Page 184 Standalone DVR User’s Manual Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP.  User name: It is optional. You can input your commonly used email address. Important ...
  • Page 185 Standalone DVR User’s Manual Figure 5-33 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25. You can modify it if necessary. Anonymity For the server supports the anonymity function.
  • Page 186 Standalone DVR User’s Manual Parameter Function Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not. (interval) Please check the box to enable this function and then set the corresponding interval.
  • Page 187 Standalone DVR User’s Manual Figure 5-35 5.8.2.12 SNMP The SNMP interface is shown as in Figure 5-36. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop.
  • Page 188 Standalone DVR User’s Manual Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write.
  • Page 189 Standalone DVR User’s Manual 5.8.2.15 Alarm Centre The alarm centre interface is shown as below. See Figure 5-39. This interface is reserved for you to develop. System can upload alarm signal to the alarm centre when local alarm occurs. Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data.
  • Page 190 Standalone DVR User’s Manual Figure 5-41 You can see the corresponding prompt. See Figure 5-42. Now the server certificate is successfully created. Figure 5-42 5.8.2.16.2 Download root certificate In Figure 5-40, click button, system pops up a dialogue box. See Figure 5-43. Figure 5-43 Click Open button, you can go to the following interface.
  • Page 191 Standalone DVR User’s Manual Figure 5-44 Click Install certificate button, you can go to certificate wizard. See Figure 5-45. Figure 5-45 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-46.
  • Page 192 Standalone DVR User’s Manual Figure 5-46 Click Next button, you can see the certificate import process is complete. See Figure 5-47. Figure 5-47 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-48.
  • Page 193 Standalone DVR User’s Manual Figure 5-48 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-49. Figure 5-49 5.8.2.16.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-50. You can see HTTPS default value is 443.

  • Page 194: Event

    Standalone DVR User’s Manual 5.8.3 Event 5.8.3.1 Video detect 5.8.3.1.1 Motion Detect The motion detect interface is shown as in Figure 5-51. Figure 5-51 Figure 5-52...
  • Page 195 Standalone DVR User’s Manual Figure 5-53 Figure 5-54 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list.
  • Page 196 Standalone DVR User’s Manual Parameter Function Period Motion detection function becomes activated in the specified periods. See Figure 5-52. There are six periods in one day. Please draw a circle to enable corresponding period. Click OK button, system goes back to motion detection interface, please click save button to exit.
  • Page 197 Standalone DVR User’s Manual Here you can set PTZ movement when alarm occurs. Such as go Activation to preset X. See Figure 5-54. Video Matrix This function is for motion detect only. Check the box here to enable video matrix function. Right now system supports one-channel tour function.
  • Page 198 Standalone DVR User’s Manual Figure 5-56 5.8.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.8.3.2.1 Local Alarm The local alarm interface is shown as in Figure 5-57. It refers to alarm from the local device.
  • Page 199 Standalone DVR User’s Manual Figure 5-58 Figure 5-59 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
  • Page 200 Standalone DVR User’s Manual Parameter Function whole week. Click OK button, system goes back to local alarm interface, please click save button to exit. System only memorizes one event during the anti-dither Anti-dither period. The value ranges from 5s to 600s. There are two options: NO/NC.
  • Page 201 Standalone DVR User’s Manual Figure 5-60 5.8.3.3 Alarm Output It is to set alarm output mode. See Figure 5-61. Figure 5-61 5.8.3.4 Abnormality It includes two types: No disk, disk error, disk no space, net disconnection, IP conflict and MAC conflict. See Figure 5-62 and Figure 5-63. Figure 5-62...

  • Page 202: Storage

    Standalone DVR User’s Manual Figure 5-63 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, disk no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).
  • Page 203 Standalone DVR User’s Manual Figure 5-64 Figure 5-65 Figure 5-66...
  • Page 204 Standalone DVR User’s Manual Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30. Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD.
  • Page 205 Standalone DVR User’s Manual Figure 5-68 5.8.4.3 Manual Record The interface is shown as in Figure 5-69. Figure 5-69 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device.

  • Page 206: System

    Standalone DVR User’s Manual Check the corresponding All button, you can enable or disable all Start all/ stop all channels record. 5.8.5 System 5.8.5.1 General The general interface includes general, date/time and holiday setup. 5.8.5.1.1 General The general interface is shown as in Figure 5-70. Figure 5-70 Please refer to the following sheet for detailed information.
  • Page 207 Standalone DVR User’s Manual Figure 5-71 Please refer to the following sheet for detailed information. Parameter Function Here you can select date format from the dropdown list. Date format There are two options: 24-H and 12-H. Time Format The time zone of the device. Time zone It is to set system time.
  • Page 208 Standalone DVR User’s Manual Figure 5-72 5.8.5.2 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 5.8.5.2.1 GUI Here you can set background color and transparency level. See Figure 5-73. Figure 5-73 Please refer to the following sheet for detailed information. Parameter Function There are four options: 1920×...
  • Page 209 Standalone DVR User’s Manual Figure 5-74 5.8.5.2.3 Tour The tour interface is shown as in Figure 5-75. Here you can set tour interval, split mode, motion detect tour and alarm tour mode. Figure 5-75 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function.
  • Page 210 Standalone DVR User’s Manual Figure 5-76 Please refer to the following sheet for detailed information. Parameter Function This function is disabled by default. Check the box here to enable Enable this function so that you can control the zero-channel encoding function at the WEB.
  • Page 211 Standalone DVR User’s Manual 5.8.5.4 RS232 The RS232 interface is shown as in Figure 5-78. Figure 5-78 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200.
  • Page 212 Standalone DVR User’s Manual Please refer to the following sheet for detailed information. Parameter Function Select speed dome connected channel. Channel You can select control mode from the dropdown list. There are two Control mode options: Serial/HDCVI. For HDCVI series product, please select HDCVI.
  • Page 213 Standalone DVR User’s Manual 5.8.5.6.2 Network Type The network type interface is shown as below. See Figure 5-81. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements. With the protocol For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number).
  • Page 214 Standalone DVR User’s Manual 5.8.5.7 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits. The space in the front or at the end of the string is null. The valid string includes: character, number, and underline.
  • Page 215 Standalone DVR User’s Manual Figure 5-84 Modify user It is to modify the user property, belonging group, password and rights. See Figure 5-85. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup.
  • Page 216 Standalone DVR User’s Manual Figure 5-85 5.8.5.7.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-86. Figure 5-86 Add group: It is to add group and set its corresponding rights. See Figure 5-87. Please input the group name and then check the box to select the corresponding rights.
  • Page 217 Standalone DVR User’s Manual includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 5-87 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-88. Here you can modify group information such as remarks and rights. Figure 5-88...
  • Page 218 Standalone DVR User’s Manual 5.8.5.8 Auto maintain The auto maintain interface is shown as in Figure 5-89. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.

  • Page 219: Information

    Standalone DVR User’s Manual 5.8.5.11 Upgrade The upgrade interface is shown as in Figure 5-92. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.

  • Page 220: Connection Log

    Standalone DVR User’s Manual Figure 5-94 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.

  • Page 221: Online User

    Standalone DVR User’s Manual Figure 5-95 5.9.4 Online User The online user interface is shown as in Figure 5-96. Figure 5-96 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-97. Please set record type, record date, window display mode and channel name. You can click the date on the right pane to select the date.
  • Page 222 Standalone DVR User’s Manual Figure 5-97 Then please click File list button, you can see the corresponding files in the list. See Figure 5-98. Figure 5-98 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen.
  • Page 223 Standalone DVR User’s Manual Figure 5-99 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 5-100. The Download button becomes Stop button and there is a process bar for your reference. Please go to you default file saved path to view the files.
  • Page 224 Standalone DVR User’s Manual Load more It is for you to search record or picture. You can select record channel, record type and record time to download. There are two download types. The download by file interface is shown as in Figure 5-101 and the download by time interface is shown as in Figure 5-102. Figure 5-101 Figure 5-102 Watermark...

  • Page 225: Alarm

    Standalone DVR User’s Manual Figure 5-103 5.11 Alarm Click alarm function, you can see an interface is shown as Figure 5-104. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.). Figure 5-104 Please refer to the following sheet for detailed information.

  • Page 226: Log Out

    Standalone DVR User’s Manual Type Parameter Function Operation Prompt Check the box here, system can automatically pops up an alarm icon on the Alarm button in the main interface when there is an alarm. Alarm Play alarm System sends out alarm sound when an alarm Sound sound occurs.

  • Page 227: Professional Surveillance System

    Standalone DVR User’s Manual 6 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.

  • Page 228: Faq

    Standalone DVR User’s Manual 7 FAQ DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon.
  • Page 229 Standalone DVR User’s Manual  DVR and monitor resistance is not compatible.  Video transmission is too long or degrading is too huge.  DVR color or brightness setup is not correct. I can not search local records. There are following possibilities: ...
  • Page 230 Standalone DVR User’s Manual  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and DVR protocol is not compatible.  PTZ decoder and DVR address is not compatible. ...
  • Page 231 Standalone DVR User’s Manual  MAC address conflict.  PC or DVR network card is not good. 16. Burn error /USB back error. There are following possibilities:  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.
  • Page 232 Standalone DVR User’s Manual  Camera quality is too low. Lens is dirty. Camera is installed against the light. Camera aperture setup is not correct.  HDD capacity is not enough.  HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: ...
  • Page 233 Standalone DVR User’s Manual There are following possibilities:  Check the camera is online or not.  Check IP channel setup is right or not (such as IP address, user name, password, connection protocol, port number.).  The camera has set the whitelist (Only the specified devices can connect to the camera).
  • Page 234 Standalone DVR User’s Manual  Do not connect the TV to the local video output port (VOUT).It may result in video output circuit.  Always shut down the device properly. Please use the shutdown function in the menu, or you can press the power button in the front pane for at least three seconds to shut down the device.

  • Page 235: Appendix A Hdd Capacity Calculation

    Standalone DVR User’s Manual Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.
  • Page 236 Standalone DVR User’s Manual 448K 196M 512K 225M 640K 281M 768K 337M 896K 393M 1024K 450M 1280K 562M 1536K 675M 1792K 787M 2048K 900M...

  • Page 237: Appendix B Compatible Backup Devices

    Standalone DVR User’s Manual Appendix B Compatible backup devices Appendix B-1 Compatible USB list Manu factor Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ...

  • Page 238: Appendix B-2 Compatible Sd Card List

    Standalone DVR User’s Manual Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix B-2 Compatible SD Card list Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Small Sandisk Small...

  • Page 239: Appendix B-6 Compatible Sata Hdd List

    Standalone DVR User’s Manual Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix B-6 Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500G to 4T capacity. Port Manufacturer Series...
  • Page 240 Standalone DVR User’s Manual Seagate Seagate Pipeline HD2 ST31000322CS SATA Seagate Seagate Pipeline HD2 ST1000VM002 SATA Seagate Seagate Pipeline HD2 ST1500VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM003 SATA Seagate Seagate Constellation ST3500514NS 500G SATA Seagate Seagate Constellation ST31000524NS...
  • Page 241 Standalone DVR User’s Manual Westem Digital Cariar SE WD2500JS 250G SATA Westem Digital Cariar SE16 WD7500KS 750G SATA Westem Digital Cariar SE16 WD5000KS 500G SATA Westem Digital Cariar SE16 WD4000KD 400G SATA Westem Digital Cariar SE16 WD3200KS 320G SATA Westem Digital Cariar SE16 WD2500KS 250G...
  • Page 242 Standalone DVR User’s Manual Hitachi HitachiCinemaStar™ HCP725050GLA380 500G SATA 5K500 Hitachi HitachiCinemaStar™ HCT721050SLA360 500G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721075SLA360 750G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...

  • Page 243: Appendix Ccompatible Cd/Dvd Burner List

    Standalone DVR User’s Manual Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner.

  • Page 244: Appendix D Compatible Displayer List

    Standalone DVR User’s Manual Appendix D Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch HFNOVO（LCD） LXB-L17C 17-inch 22 寸(wide screen) SANGSUNG（LCD）...

  • Page 245: Appendix E Compatible Switcher

    Standalone DVR User’s Manual Appendix E Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes 1. AUTO 2. HALF-10M Ruijie RG-S1926S 3. FULL-10M 4 .HALF-100M 5. FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK...

  • Page 246: Appendix Fcompatible Wireless Mouse List

    Standalone DVR User’s Manual Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630...

  • Page 247: Appendix G Channel Settings Info Of Hybrid Mode

    Standalone DVR User’s Manual Appendix G Channel Settings Info of Hybrid Mode Model Hybrid Mode  Eagle-04 3-channel 960H analog+1-channel 720P  2-channel 960H analog+2-channel 720P or 1-channel 1080P  Eagle-16 14-channel 960H analog+2-channel 720P or 1-channel 1080P  12-channel 960H analog+4-channel 720P or 2-channel 1080P Falcon-04E 1-channel D1+2-channel CIF+1-channel 720P...

  • Page 248: Appendix H Earthing

    Standalone DVR User’s Manual Appendix H Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
  • Page 249 Standalone DVR User’s Manual  Signal lightning arrester: This device is mainly used in the PC network, communication system. The connection type is serial connection. Once you connected the signal lightning arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work.
  • Page 250 Standalone DVR User’s Manual conductance of the ground conductor. In the high-frequency circuit, you need to use the multiple-point ground mode and each cable needs to connect to the ground. The length shall be less than the 1/20 of the signal wavelength. Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground.
  • Page 251 Standalone DVR User’s Manual  The thunder proof ground shall adopt the special ground cable from the monitor control room to the ground object. The ground cable adopts copper insulation cable or wire and its ground section shall be more than 20mm2. ...
  • Page 252 Standalone DVR User’s Manual For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.
  • Page 253 Standalone DVR User’s Manual...

  • Page 254: Appendix I Toxic Or Hazardous Materials Or Elements

    Standalone DVR User’s Manual Appendix I Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○...
  • Page 255 Standalone DVR User’s Manual...
  • Page 256 Smart DVR Quick Start Guide Version 2.0.0...
  • Page 257 Welcome Thank you for purchasing our DVR! This quick start guide will help you become familiar with our DVR in a very short time. Before installation and operation, please read the following safeguard and warning carefully! Important Safeguard and Warning All installation and operation here should conform to your local electrical safety codes.
  • Page 258 4. Turn the device upside down 6. Connect the HDD cable and Fix the HDD firmly. and then turn the screws in power cable. firmly. 7. Put the cover in accordance 8. Secure the screws in the with the clip and then place the rear panel and the side panel.
  • Page 259 Please refer to the following sheet for detailed information. Name Function HDD status indictor light The red light becomes on when HDD is abnormal. The red light becomes on when the power Power indicator light connection is OK. Network status indicator The red light becomes on when the network light connection is abnormal.
  • Page 260 Figure 3 Open IE and input DVR address in the address column. For example, if your DVR IP is 10.10.3.16, then please input http:// 10.10.3.16 in IE address column. System pops up warning information to ask you whether install webrec.cab control or not. Please click yes button.
  • Page 261 Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ Panel ○ ○ ○ ○ ○ ○ Circuit Board ○ ○ ○ ○ ○...

This manual is also suitable for:

Eagle-04 seriesEagle-16 series

Table of Contents
