Eclipse Security Tribrid User Manual page 219

Please refer to the following sheet for detailed information.
Parameter Function
It is to set device name.
Device ID
Device No. It is device channel number.
Language You can select the language from the dropdown list.
Please note the device needs to reboot to get the modification
activated.
Video This is to display video standard such as PAL.
Standard
Here is for you to select working mode when hard disk is full. There
HDD full
are two options: stop recording or rewrite. If current working HDD is
overwritten or the current HDD is full while the next HDD is no empty,
then system stops recording, If the current HDD is full and then next
HDD is not empty, then system overwrites the previous files.
Here is for you to specify record duration. The value ranges from 1 to
Pack
120 minutes. Default value is 60 minutes.
duration
5.8.5.1.2 Date and time
The date and time interface is shown as in Figure 5-75
HDCVI Standalone DVR User's Manual
Figure 5-74
210
