Head and Ram Illustration and Parts List—EK210L
10
9
Key Part No. Description
1 50120050 Bushing with seal ...................................... 1
52055862 Die holder kit (includes 2–6, 9, 10)
2 Shoulder bolt ............................................. 1
3 Cap ............................................................ 1
4 Compression spring .................................. 1
5 Compression spring .................................. 1
6 Washer ...................................................... 1
Greenlee / A Textron Company
Battery-powered In-line Tools
11
5
6
7
8
Qty Key Part No.
7 52055011
8 50019295
9 50019716
10
11 50019708
12*
9
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
12
1
2
3
4
Description
Crimping head ........................................... 1
Screw ........................................................ 1
Screw ........................................................ 2
Die holder .................................................. 1
Pinch hazard decal .................................... 1
Seal bushing (included in 50047957) ........ 1
Qty
