Greenlee GATOR EK6IDL Service Manual page 15

Head and Ram Illustration and Parts List—ETS8L
Key Part No. Description
1 50120050 Bushing with seal ...................................... 1
52024565 Cutter blade kit (includes 2–5)
2 Cutter plate ............................................... 1
3 Cutting rod ................................................ 1
4 Spring-type straight pin ............................ 1
5 Socket head cap screw, m5-14 ................ 1
Greenlee / A Textron Company
9
4
2
Battery-powered In-line Tools
3
7
6
8
5
Qty Key Part No.
6 50019295
7 50019120
8 52026760
9 52024564
10*
15
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
10
1
Description
Hex head cap screw, m3x4 ....................... 1
Compression spring .................................. 1
Cutter head ............................................... 1
Pinch hazard decal .................................... 1
Seal bushing (included in 50047957) ........ 1
Qty
