Greenlee GATOR EK6IDL Service Manual page 10

Head and Ram Illustration and Parts List—EK410L
16
15
13
Key Part No. Description
1* O-ring (included in 50047957) ................... 1
2* Piston backup ring
(included in 50047957) .............................. 1
3 50019082 Bushing ..................................................... 1
50018981 Head unit (includes 4–16)
52055863 Ram kit (includes 4–6, 14, 15)
4 Shoulder bolt ............................................. 1
5 Disc ........................................................... 1
6 Spring ........................................................ 1
7 50019180 Fixed head ................................................. 1
Greenlee / A Textron Company
17
14
11
10
12
Battery-powered In-line Tools
5
6
7
8
9
Qty Key Part No.
52055864
8
9
10
11
52040994
12
13
14
15
16
17 50019708
10
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
2
3
4
Description
Hardware kit (includes 8–11, 13, 14)
Screw ........................................................ 1
Retaining ring ............................................ 4
Pin ............................................................. 2
Spring ........................................................ 2
Head and latch kit (includes 12, 16)
Movable head ............................................ 1
Screw ........................................................ 1
Pin ............................................................. 1
Ram adapter.............................................. 1
Latch head ................................................ 1
Pinch hazard decal .................................... 1
1
Qty
