- Page 1 ® EK1230L and EK1230CL Battery-powered Crimping Tools Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 52047657 REV 3 © 2011 Greenlee Textron Inc. 9/11...
-
Page 2: Table Of Contents
For recycling information, go to www.greenlee.com. All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. GATOR is a registered trademark of Greenlee Textron Inc. -
Page 3: Important Safety Information
Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 4: Important Safety Information
Note: Keep all decals clean and legible, and replace • Use this tool for the manufacturer’s intended when necessary. purpose only. Failure to observe these precautions may result in injury or property damage. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 5: Identification
18 V, 3 Ah lithium-ion battery 52054992 Li (18 V) to NiCd, NiMH (12 V) charger adapter 52049201 120 VAC, 18 V charger 50122746 Carrying strap Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 6: Operation
• If the tool is unable to reach the required crimp force, the red LED, work light, and an audible beep will pulse until after the trigger is released. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 7: Operation
1ST COMPRESSION complete. SIDE A Failure to observe these warnings could result in severe injury or death. 1ST COMPRESSION SIDE B CRIMPING DIRECTION SIDE A Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 8: Die Selection
YA-A ACL/ACN 60176; 400 to Aluminum VACL BLUA number provided with YA-ATN 2ACL/2ACN 60230 to 750 kcmil: Lugs the connector. 60278 3 crimps Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 9: Maintenance
2. Check the oil level. grene, or death. Annually or After 10,000 Crimps 1. Replace the hydraulic oil. 2. Send the tool to a Greenlee Authorized Service Center for inspection. Do not use solvents or flammable Checking the Oil Level liquids to clean the tool body. -
Page 10: Troubleshooting
