- Page 1 Serial Number GATOR EK622L ® Battery-powered Crimping Tool Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 52047665 REV 3 © 2012 Greenlee Textron Inc. 3/12...
-
Page 2: Table Of Contents
For recycling information, go to www.greenlee.com. All specifications are nominal and may change as design improve- ments occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. GATOR is a registered trademark of Greenlee Textron Inc. -
Page 3: Important Safety Information
Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 4: Important Safety Information
Note: Keep all decals clean and legible, and replace • Use this tool for the manufacturer’s intended when necessary. purpose only. Failure to observe these precautions may result in injury or property damage. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 5: Identification
18 V, 1.5 Ah lithium-ion battery 52049202 230 VAC, 18 V charger 52049189 18 V, 3.0 Ah lithium-ion battery 52049204 12 VDC, 18 V charger Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 6: Operation
• If the tool is unable to reach the required crimp force, the red LED, work light, and an audible beep will pulse until after the trigger is released. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 7: Operation
1. Push the die release button. 6. The crimping tool returns automatically. 2. Slide the die adapter (Greenlee part number 7. Position the crimping tool for next crimp. Repeat 50042920) into crimping head until it “snaps” into Steps 4 through 6 for the number of crimps as place. -
Page 8: Die And Connector Selection
EK622L Battery-powered Crimping Tool Die Selection Crimps made on copper cable with Greenlee KC22-type dies and the copper connectors listed here are cUL and UL classified. Crimps made on copper or aluminum cable with Greenlee KA22-type dies and the dual-rated aluminum connectors listed here are cUL and UL classified. -
Page 9: Maintenance
2. Check the oil level. grene, or death. Annually or After 10,000 Crimps 1. Replace the hydraulic oil. 2. Send the tool to a Greenlee Authorized Service Center for inspection. Do not use solvents or flammable Checking the Oil Level liquids to clean the tool body. -
Page 10: Troubleshooting
Dirt, contaminants, etc., Clean tool. in ram area of tool. Tool battery contacts damaged. Reform contacts. Tool components worn or Return tool to a Greenlee Authorized Service damaged. Center. Motor is inoperative. Low or uncharged battery. Try known charged battery. Inoperative battery may be discharged or may have reached life expectancy. - Page 11 EK622L Battery-powered Crimping Tool Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
