13. PARTS LIST

Regarding the rank of spare parts
Rank A: This rank of part will be stocked always until product discontinued.
Rank B: This rank of part will not be stocked always. This parts will need a lead time maximumly 3 month.
Rank C: This rank of part will not be stocked always. This parts will need a lead time at least 3 month.
Rank D: This rank of part will not be supplied as spare parts.
The parts will be supplied during five years unless the part run out after discontinued product.
Some of outer parts may not be supplied after discontinued product.
13.1 Outer Casing
No. Part No.
1 641300000 Control Panel 3SB
2 480003061 M3L6 Binding Head Screw
3 480004061 M4L6 Binding Head Screw
4 641300071 Rear Cover
5 641050090 Left Side Cover
641060170 Model Name Label CS510-11eN
641060150 Model Name Label CS510-11eN PRO
6
641050360 Model Name Label IS210-11eN
641050340 Model Name Label IS210-11eN PRO
7 640310450 Document Guide
8 641300700 USB/NET Label
9 391526069 M2.6L6 Self Tapping Screw
10 774105000 Front Guide Assembly
11 774105507 Relay Board
12 641050060 Right Side Cover
Outer Casing
4
5
CS510/IS210-UM-251-9370
Part name
Document Guide IS31
6
10
13-1
Description Q'ty
1
4
6
1
1
1
1
1
1
3
1
2
1
1
1
7
13. PARTS LIST
Remarks SR
CS510-11eN
CS510-11eN PRO
IS210-11eN
IS210-11eN PRO
CS510-11eN/IS210-11eN
2
3
9
1 11 12 8
A
D
D
C
C
C
C
C
C
C
C
C
C
C
C
