SPECIFICATIONS

POWER INPUTS
Motors not running: 10.0 VDC – 28.0 VDC 0.1A
Single Motor Stalled Max Peak: 10.0 VDC – 28.0 VDC 3.1A
Single Motor Stalled Max Continuous: 10.0 VDC - 28.0 VDC 2.1A
Three Motors Stalled Max Peak: 10.0 VDC - 28.0 VDC 9.1A
Three Motors Stalled Max Continuous: 10.0 VDC - 28.0 VDC 6.1A
POWER OUTPUTS
CAN Port: Voltage = VBA IN, 5A Max Time Delay Fused
CAM/RS232 Port: 5VDC, 200mA Thermal Resettable Fuse
DIGITAL OUTPUTS
CAM/RS232 Port Pin 5: 200mA Thermal Resettable Fuse
CAM/RS232 Port Pin 6: 25mA Max
RADIO TRANSMITTER
Frequency: 2.410 - 2.465 GHz
Transmitter Power: Power Level 0 (EU): +10dBm, Power Level4: +18 dBm
CAM/RS232 Port Pin 6: 25mA Max
PHYSICAL
Weight: 111 grams (Including Antenna, exluding MōVI Top Rail Mount)
Dimensions: 122mm x 55mm (Including Antenna, exluding MōVI Top Rail Mount)
