HOW TO
HOW TO SET UP CAMERA RUN/STOP
1 Navigation: Home -> FIZ Config -> Camera Type (Scroll SET).
2 Settings Action: Save (Scroll SET).
3 Press SET Button.
4 Connect the selected camera connection cable.
HOW TO SET UP YOUR MOTOR TYPE
1 Navigation: Home -> FIZ Axis Cfg -> Motor Model (Scroll SET).
2 Settings Action (Scroll SET to Save).
3 Press SET Button.
AUTOMATIC CALIBRATION OF ALL AXES SIMULTANEOUSLY
1 Navigation: Main -> FIZ Main -> CAL.
2 Press SET Button.
3 Motors will test motion in both directions, then sense hard stops.
AUTOMATIC CALIBRATION OF A SINGLE AXIS
1 Navigation: Main -> FIZ Detail -> CAL: AT (Scroll SET to AT).
2 Press SET Button.
1 Motors will test motion in both directions, then sense hard stops.
2 Status is displayed in the "STAT:" field on the display.
