MENU STRUCTURE
HOME
The home menu is the starting point for navigating through other MōVI Controller menus. You can always return to the Home menu by scrolling to and clicking the
Home icon in the top-left corner of the display.
TX MONITOR
The transmitter (Tx) Monitor menu displays information about the transmitted user inputs. The Pan/Tilt Joystick, Focus Wheel, Zoom Rocker, Iris Knob, Record Button,
and other knobs and switches report their position in this menu. This information can be useful for holding consistent pan, tilt, or zoom rates.
TX CONFIG
User inputs and the MōVI Controller operation can be customized from the Tx Config menu:
• TX ACTION: Load, Save, or Restore MōVI Controller Transmitter Configurations
Save Tx Configuration to non-volatile (flash) memory from here.
SAVE
Settings changes not saved before powering down the MōVI Controller will be lost.
Load the most recently saved Tx Configuration from non-volatile (flash) memory. This can be useful for undoing changes made since the
LOAD
last power up.
DEFAULT
Temporarily restore the default factory Tx Configuration. Save this configuration permenantly using
Reset the center point of the Pan/Tilt Joystick and Zoom Rocker. These inputs are zeroed on start-up. Check the center points in the
RE-ZERO
Tx Monitor men. If pan, tilt, or zoom has more than 1-2% of offset when the joystick and zoom rocker are in their center positions, it can
create slow drift of the MōVI.
CALIBRATE
Re-calibrate the end points of the Focus Knob. See Calibration section for calibration instructions.
• MAP ROLL INPUT:
Assign an input (Zoom Rocker, Iris Knob, etc.) to control the MōVI Roll Axis
• FOCUS DIRECTION:
Reverse the direction of the Focus Knob input.
• ZOOM DIRECTION:
Reverse the direction of the Zoom Rocker input
• IRIS DIRECTION:
Reverse the direction of the Iris Knob input.
• PAN DIRECTION:
Reverse the direction of the Pan/Tilt Joystick X-Axis (Pan). The Pan/Tilt Joystick Y-Axis (Tilt) can be reversed using the
Tilt Direction Switch.
P17
Tx Action::Save
as described above.
