AUXILIARY TRANSMITTER
The MōVI Controller Receiver can optionally be used as an Auxiliary Transmitter for controlling third-party wireless follow-focus systems. For more information on
supported systems, see the Follow-Focus Integration section. To change modes:
1 - Move the Receiver Channel Switch to the position indicated in the table below.
2 - Hold down the FW Button and then press the Bind Button once.
3 - The new mode will be active after the next power cycle.
MODE
MōVI Controller Receiver Status LED:
(Solid Green)
Set Channel: 0 - C
Press Bind Button while holding down FW Button.
microRemote Auxiliary Transmitter Status LED:
(Slow-flashing green/orange)
Set Channel: D
Press Bind Button while holding down FW Button.
Axis 1 Auxiliary Transmitter Status LED:
(Fast-flashing green/orange)
Set Channel: E
Press Bind Button while holding down FW Button.
1 Auxiliary Transmitters and Auxiliary Data Port connector are sold separately.
P28
CONNECTS TO
MōVI Gimbal Controller, MōVI Data Port.
(See Receiver Installation section.)
MōVI Controller Auxiliary Data Port.1
MōVI Controller Auxiliary Data Port.1
DESCRIPTION
This is the normal operating mode for two-way
communication from the MōVI Controller to the
MōVI. The Receiver thatcomes included with the
MōVI Controller is in this mode by default.
In this mode, the MōVI Controller Receiver acts
as an Auxiliary Transmitter for sending commands
to a Redrock Micro microRemote Basestation.
In this mode, the MōVI Controller Receiver acts
as an Auxiliary Transmitter for sending commands
to a Hocus Products Axis 1 Digital Receiver.
