FOCUS MAPPING POINTS
These Screens are used to map the focus axis points. The Infinity, and close focus points must be added while the others are optional. The Controller sugests
common mapping points that are typically marked on Cinema prime lenses of the selected focal length, however, these can be adjusted if necessary, and should
certainly be adjusted if they are not marked on the lens. You will get the best mapping accuracy if you use all of the marked points if possible. After entering the close
focus point, the values should increase towards the last marked point before infinity, which should be last mapped point.
The order they are added in is:
1. Infinity: This typically marked as the ∞ symbol on the lens.
2. Close Focus: This is the closest marked distance on the lens.
3. Intermediate Focus points: Recommended based on the focal length of the lens, and marks commonly found on cinema prime lenses of that length.
4. Finish Early: The "Finish" option should be used if there are no more marked positions on the lens and there are still points left.
P43
