Troubleshooting - Freefly M?VI Controller User Manual

TROUBLESHOOTING

SYMPTOM
Transmitter will not power on. (No display)
Cannot connect to a MōVI.
Receiver Status LED:
(None)
Cannot connect to a MōVI.
Receiver Status LED:
(Fast-Flashing Green)
Can control a MōVI, but the data/telemetry is not
present or corrupted. Receiver Status LED :
(Solid Green)
P26
POSSIBLE CAUSE
Incompatible power supply or low battery.
The Receiver is not powered.
Unsupported MōVI firmware or incorrect radio
type in MōVI Configurator.
The connection is still starting.
The MōVI Controller and Receiver are on different
channels.
The connection is still starting.
The Receiver is new and/or not bound to the MōVI
Controller.
Multiple bound MōVIs are on at the same time.
SOLUTION
Ensure that the voltage supplied to the MōVI
Controller is 13.0-20.0V (or 4.5-5.5V for USB power
input). If using a battery, check that the battery is
charged.
Make sure the Receiver is installed correctly
and the MōVI is powered on. See installation
instructions in the Receiver section.
Update to MōVI firmware v3.08 or later and
configure theRadio Type to "FTX" in the MōVI
Configurator App.
Wait for the connection to be established:
Channel 1 thru C: < 5 seconds
Channel 0 (Auto): < 15 seconds
Set the Receiver to the same channel as the
MōVI Controller (Radio Config::Channel), or to
Channel 0 (Auto).
Change the MōVI Controller Device Group
Config::Device Group) to the one into which the
Receiver was bound. (The default Device Group is
00.)
Follow the instructions for binding a new Receiver
in the Receiver section.
Turn off MōVIs that are bound to this MōVI
Controller but not in use, or re-bind the other
MōVIs into different Device Groups.
(Radio
