Freefly M?VI Controller User Manual page 18

• RECORD TYPE: Change the shutter/record output on the MoVI Controller Receiver.
MOMENTARY The Shutter/Record Output is active only while the Record Start/Stop Button is pressed.
TOGGLE The Shutter/Record Output switches between active and inactive each time the Record Start/Stop Button is pressed.
• RECORD POLARITY: Change the active state of the Shutter/Record Output signal from the MoVI Controller Receiver.
NORMAL The Shutter/Record Output is active high (3.3V digital output).
REVERSE The Shutter/Record Output active low (0.0V digital output).
• USER 3 Function:
Assign a function to the USER 3 switch. See User Functions table below.
• TILT REV Function: Configure the function of the TILT REV switch center position.
NORMAL The Center position is the same as the Up position (TILT FWD).
REVERSE The Center position disables the Tilt Axis.
• USER 1 Function: Assign a function to the USER 1 knob. See User Function table below. The USER 1 function assignment has priority over
USER 2 and USER 3.
• USER 2 Function: Assign a function to the USER 2 knob. See User Function table below. The USER 2 function assignment has priority
over USER 3.
P18
