Input selection settings

1/ In the MENU section, press the
Input in the menu by rotating the scroll knob. Then press the
[ENTER] button to enter the Input sub-menu.
2/ In the Input menu, select the type of input you have plugged into
the OPS200 by rotating the scroll knob (see Input Specifications).
Then press the
connected to the OPS200.
3/ Press the [EXIT/MENU]
4/ Repeat steps #1 through #3 for every source connected to your
OPS200.

Source output selection

Once your inputs have all been configured, the output settings of
the OPS200 must be set according to the machines plugged on
your OPS200 main and preview outputs (video projector, preview
monitor...).
* NOTE * : It is strongly recommended to set the output format of
the OPS200 to match the native resolution of the display devices
connected to the OPS200.

Output selection settings

1/ In the Menu section, press the
Output in the menu by rotating the scroll knob. Then press the
[ENTER] button to enter the Output sub-menu.
2/ In the Output menu, select the output type, resolution and frequency,
to match the viewing hardware plugged into the OPS200, by
rotating the scroll knob (see also Output Specifications). Then
press the [ENTER]
* NOTE * : be sure to press the [ENTER] button to confirm every
selected setting, the OPS200, will revert to its original settings if new
choices are not confirmed.
3/ Press the [EXIT/MENU]
28
[EXIT/MENU]
[ENTER] button to enter the types of inputs
button to return to the main menu.
[EXIT/MENU]
button to enter each of the output parameters.
button to return to the main menu.
button and select
button and select
